Intel Server System D50TNP2MHSTAC Storage Module Intel C621A LGA 4189 Rack (2U)
MPN
D50TNP2MHSTAC
About this item
Intel® Server System D50TNP2MHSTAC Storage Module , Single
The Storage Modules in the D50TNP family are 2U, half-width modules intended for dense and fast storage solutions. The Storage Module supports up to two SATA or PCIe M.2 storage SSDs and can support up to 16 full-length (E1.L) Enterprise and Datacenter SSD Form Factor (EDSFF) NVMe SSDs. They provide the fastest storage interface and maximum storage capacity available in a single high density module. The Storage Modules are available for air-cooled configurations.
Specifications
Processor
| Built-in processor | |
| Motherboard chipset | Intel C621A |
| Processor socket | LGA 4189 |
| Number of processors supported | 2 |
Memory
| Number of DIMM slots | 24 |
| Memory channels | Hexadeca-channel |
| ECC | |
| Supported memory types | DDR4-SDRAM |
| Maximum internal memory | 6000 GB |
| Memory bandwidth (max) | 204.8 GB/s |
Storage
| Number of storage drives supported | 16 |
| Supported storage drive interfaces | PCI Express, Serial ATA |
| RAID levels | 0,1,5 |
Networking
| Ethernet interface type | 10 Gigabit Ethernet |
| Ethernet LAN |
Ports & interfaces
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 3 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Number of SATA connectors | 2 |
| Serial ports quantity | 1 |
Expansion slots
| PCI Express slots version | 4.0 |
| PCI Express x16 slots | 2 |
Graphics
| On-board graphics adapter model | Aspeed AST2500 |
Design
| Rack-Friendly board | |
| Chassis type | Rack (2U) |
Performance
| Trusted Platform Module (TPM) | |
| Trusted Platform Module (TPM) version | 2.0 |
| Intel Intelligent Power Node Manager | |
| Intel Advanced Management Technology | |
| Integrated BMC with IPMI |
Features
| Number of UPI links | 3 |
| Intel Node Manager | Y |
| Embedded options available | |
| Harmonized System (HS) code | 8473301180 |
| Commodity Classification Automated Tracking System (CCATS) | G157815L1 |
| Export Control Classification Number (ECCN) | 5A002U |
Technical details
| Target market | High Performance Computing |
| USB ports quantity | 3 |
| Packaging content | (1) Intel® Server Board D50TNP1SB (1) 2U half-width module tray – iPN K74857 (1) 1U storage module air duct right – iPN K88592 (1) 1U storage module air duct left – iPN K88590 (2) 1U riser bracket to support TNP1URISER – iPN K25206 (2) M.2 heat sink assembly TNPM2HS (1) 1U Air-Cooled front Heat Sink TNP1UHSF (1) 1U Air-Cooled Rear Heat Sink TNP1UHSB (2) Processor clip, for 3rd Gen Intel® Xeon® Scalable processor family – iPN J98484 (1) Storage Compute Module Docking Board TNPSTDCKBRD (2) OCuLink cable 520 mm – iPN K73563 (2) OCuLink cable 125 mm – iPN K73567 (2) OCuLink cable 145 mm – iPN K73568 (2) OCuLink cable 140 mm – iPN K73570 (1 each) OCuLink connector covers for J25, J26, J29, and J30 – iPN K74231 (1 each) OCuLink connector covers for J27 and J28 – iPN K74230 |
| Expected discontinuance date | 2025 |
| Riser slot 1 number of lanes | 32 |
| Extended warranty available for purchase (select countries) | Y |
| Riser slot 2 number of lanes | 24 |
| Intel Virtualization Technology for Directed I/O (VT-d) | |
| Status | Launched |
| Launch date | Q3'21 |
Power
| Thermal Design Power (TDP) | 205 W |
Processor special features
| Intel® AES New Instructions (Intel® AES-NI) | |
| Intel® Optane™ Memory Ready |
Weight & dimensions
| Width | 216 mm (8.42 ") |
| Depth | 591.4 mm (23.06 ") |
| Height | 82 mm (3.2 ") |
Other features
| CPU configuration (max) | 2 |
| On-board graphics adapter | |
| Intel | |
| Y | |
| 8 |
