Kramer 20-80443090 DIP-31M 4K60 4-2-0 HDMI & Computer Graphics Automatic Video Switch

SKU

5_DIP-31M_1

Be the first to review this product

$544.00

Visit our Kramer Electronics Store

MPN

DIP-31M

Recommended Product

StarTech.com 4x4 HDMI Matrix Switch with Picture-and-Picture Multiviewer or Video Wall

$756.00

About this item

4K@60 4:2:0 HDMI & VGA Auto Switcher with Maestro Room Automation

Description
Specifications

The DIP−31M is a 4K@60Hz (4:2:0) automatic switcher for HDMI, VGA, Ethernet, data and unbalanced audio signals. It provides full room automation including control of lights, screens, shades and many other exciting options. It supports various modes of input selection and transmits the signal via HDMI cable to a compatible receiver (for example the VS−62H or a display/projector). The device is a Step−in commander when connected to a matrix switcher that supports Step−in over HDMI such as the VS−62H. It also features RS−232 commands to support monitor/projector on/off.

Specifications

Ports & interfaces

Video port type	HDMI/VGA
HDMI ports quantity	3
HDMI in	2
Number of HDMI outputs	1
VGA (D-Sub) input ports	1
RJ-45 input ports	1
3.5 mm (1/8-inch) in
3.5 mm (1/8-inch) out
RS-232 ports	1
DC-in jack

Features

Product colour	Black
Supported video modes	2160p
HD type	4K Ultra HD
LED indicators	Y
Material	Aluminium
Maximum refresh rate	60 Hz
Plug and Play
Bandwidth	10.2 Gbit/s
HDCP
Maximum resolution	3840 x 2160 pixels
Supported graphics resolutions	1920 x 1200 (WUXGA),3840 x 2160
3D

Power

Power consumption

600 mA

Certificates

RoHS compliance
Certification	WEEE

Weight & dimensions

Width	187.5 mm (7.31 ")
Depth	115 mm (4.49 ")
Height	25.4 mm (0.99 ")
Weight	400 g (0.88 lbs)

Packaging data

Package width	345 mm
Package depth	165 mm
Package height	52 mm
Package weight	1000 g

Packaging content

Number of products included

1 pc(s)

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
