NEC V652-AVT computer monitor 165.1 cm
MPN
V652-AVT
UPC
805736045505
About this item
- V652-AVT - 165.1 cm (65") , 1920 x 1080 Full HD, 16:9, 320 cd/mu00b2, 4000:1, ATSC;
- High-definition broadcast capabilities through the integrated ATSC digital tuner;
- By using LED backlighting, cabinets can be made thinner and consume less power;
- Open Pluggable Specification (OPS) slot built-in, the first digital signage standardization option slot in the industry;
- Stunning detail is provided by a full 1080p high-definition resolution;
- Panels and components made of commercial-grade LCDs;
- Loop-through connectivity for expanded connectivity;
- High-quality sound is provided by integrated 10W speakers;
A 65" in-wall commercial-grade LCD display from NEC uses LED backlighting to reduce depth and power consumption compared with its predecessor.
AV inputs and an ATSC digital tuner (SB-03TM) offer digital signage users the biggest bang for their buck.
A 10W speaker and an Open Pluggable Specification (OPS)-compatible expansion slot are also included in the V652-AVT.
The display will be future-proofed and will be able to integrate seamlessly with NEC or other third-party components.
The display passes video, RS-232 control and power internally so that additional cables aren't required for installation.
The V652-AVT's full HD panel displays brilliant images and attracts the audience's attention, which makes this product perfect for applications such as retail stores, restaurants, training facilities, and corporate boardrooms, which require extended use.
Specifications
Display
| Display diagonal | 65 " |
| Display brightness (typical) | 320 cd/m² |
| Display resolution | 1920 x 1080 pixels |
| Response time | 8 ms |
| HD type | Full HD |
| Display technology | LED |
| Panel type | A-MVA |
| Supported graphics resolutions | 720 x 400,720 x 576,1280 x 960,1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),1280 x 768 (WXGA),1280 x 800 (WXGA),1400 x 1050 (SXGA+),1600 x 1200 (UXGA),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080),640 x 480 (VGA),800 x 600 (SVGA) |
| Contrast ratio (typical) | 4000:1 |
| Viewing angle, horizontal | 178 \u00b0 |
| Viewing angle, vertical | 178 \u00b0 |
| Display number of colours | 16.78 million colours |
| Native aspect ratio | 16:9 |
| Aspect ratio | 16:9 |
| 3D | |
| Display diagonal (metric) | 163.9 cm |
| Pixel pitch | 0.74 x 0.74 mm |
| Horizontal scan range | 31.5 - 91.1 kHz |
| Vertical scan range | 50 - 85 Hz |
| Viewable size, horizontal | 1428.5 mm |
| Viewable size, vertical | 803.5 mm |
| Separate H/V sync | |
| Composite sync | |
| Sync-on-green (SOG) | |
| HDCP | |
| Supported video modes | 1080i,1080p,480p,576p,720p |
| Backlight type | Edge LED |
Multimedia
| Built-in speaker(s) | |
| Number of speakers | 2 |
| RMS rated power | 20 W |
| Built-in subwoofer | |
| Built-in camera | |
| TV tuner integrated | |
| Digital signal format system | ATSC |
Design
| Market positioning | Home & Office |
| Product colour | Black |
Networking
| Bluetooth | |
| Ethernet LAN | |
| Ethernet LAN (RJ-45) ports | 1 |
Ports & interfaces
| VGA (D-Sub) ports quantity | 1 |
| DVI-D ports quantity | 2 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Composite video in | 1 |
| Headphone outputs | 1 |
| RS-232 ports | 2 |
| BNC input ports | 5 |
| Component video (YPbPr/YCbCr) in | 1 |
Ergonomics
| Cable lock slot | |
| Cable lock slot type | Kensington |
| VESA mounting | |
| VESA mounting interfaces | 400 x 400 mm |
| Plug and Play | |
| Picture-in-Picture |
Power
| Power consumption (max) | 360 W |
| Power consumption (standby) | 1 W |
| Power consumption (typical) | 185 W |
Operational conditions
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
| Storage relative humidity (H-H) | 10 - 90 % |
| Non-operating altitude | 0 - 12192 m |
| Operating altitude | 0 - 3000 m |
Certificates
| Energy Star certified | |
| Certification | RoHS |
Weight & dimensions
| Width | 1540.4 mm (60.08 ") |
| Depth | 88.3 mm (3.44 ") |
| Height | 909.2 mm (35.46 ") |
| Weight | 52000 g (114.64 lbs) |
| Width (with stand) | 1540.3 mm |
| Depth (with stand) | 512 mm |
| Height (with stand) | 944.7 mm |
| Weight (with stand) | 55100 g |
| Bezel width (side) | 53.5 mm |
| Bezel width (top) | 50.5 mm |
| Bezel width (bottom) | 50.5 mm |
Packaging data
| Package width | 1816 mm |
| Package depth | 375 mm |
| Package height | 1192 mm |
| Package weight | 67000 g |
Packaging content
| Cables included | AC, VGA |
| Handheld remote control | |
| Manual | |
| Quick start guide |
Other features
| Display | LCD |
