Seasonic 600W SSP-600ES2 ATX

Seasonic 600W SSP-600ES2 ATX is industrial power supply is compliant with version 12 V v.2.3 and is rated at 80 PLUS Bronze

The newly released ES2 fully complies with the new IEC 62368-1 safety standard.

Solid, Stable, and Efficient

It's a solid, stable, and efficient power supply that can be utilized in any ATX setup.

Its double forward converter circuit, extremely low noise fan control, and excellent protective features make it a reliable solution for a variety of applications

Seasonic 600W SSP-600ES2 ATX supports PCIe and SATA cables and has a wide range of AC inputs.

Specifications:

• Input frequency 50 / 60 Hz;
• Efficiency 80 PLUS Bronze;
• Line regulation ± 1 % (typical);
• Load regulation ± 5 % (typical);
• Cross regulation ± 5 % (typical);
• MTBF, full load @ 25 °C ambient (excl. DC fan) > 100,000 hours;
• Active Power Factor Correction 99 % (typical);

Features:

• Intel ATX 12 V v2.3 compliant; PCIe- and SATA-ready;
• High efficiency and reliability; Super low noise fan control;
• Short circuit protection on all outputs; Over voltage protection;
• Over power protection; 100 % HiPot test; 100 % Burn-in, high temperature cycled on/off;
• IEC 62368-1 compliant; Total Power: 600W; Voltage: 100 - 240V;
• Frequency: 50/60Hz; Output: +3.3V @ 24A, +5V @ 24A, +12V1 @ 24A, +12V2 @ 24A, -12V2 @ 0.3A, +5Vsb @ 2.5A;
• Main Power: ATX 12 V; Peripherals: SATA, HDD, FDD; Efficiency: 80 PLUS Bronze;
• Line regulation: +1%/- 1 % (typical); Load regulation: +5 %/- 5 % (typical); Cross regulation: +5 %/- 5 % (typical);
• MTBF, full load @ 25 C ambient (excl. DC fan): >100,000 hrs; Active Power Factor Correction: 99 % (typical);
• Safety: CB, CCC, cTUVus, TUV, BSMI; EMI / EMC: CE, FCC, RCM;
• Dimensions: 140 mm (L) x 150 mm (W) x 86 mm (H)/ (5.9 x 5.5 x 3.4 );
