Supermicro X11SSL-F server/workstation motherboard LGA 1151 (Socket H4) Intel® C232 microATX

SKU

4_X11SSL-F-B_1

Be the first to review this product

$298.00

Visit our Supermicro Store

MPN

MBD-X11SSL-F-B

UPC

672042200900

Recommended Product

Supermicro X9DBU-iF Motherboard MBD-X9DBU-IF-B

$250.00

About this item

Single socket H4 (LGA 1151), Intel Xeon E3-1200 v5, Intel C232, Up to 64GB Unbuffered ECC UDIMM DDR4 2133MHz, 4x DIMM slots, Dual GbE LAN, Bulk Pack

Description
Specifications

Supermicro's single processor Socket H4 designs feature the Intel C236/C232 chipset which support the Intel® Xeon E3-1200 v5 processor family and Intel 6th Gen Core i7/i5/i3 processor family. With outstanding features that include up to 64GB of fast DDR4 DRAM in 4 DIMMS, onboard IPMI or vPro, USB 3.0/USB 3.1, PCI-E 3.0 M.2 and SATA 3.0 (6Gbps) HDD. With support for next generation graphics controller, 4K HD graphics resolution and 3 displays with HDMI, DP, and DVI ports. Designed with performance, reliability, manageability and long life in mind, Supermicro's single processor motherboards are the perfect solution for a variety of server, workstation and embedded applications.

Specifications

Processor

Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Number of processors supported	1
Processor number of cores supported	4
Supported QPI	8 GT/s
Thermal power	80 W
Lithography	14 nm
Intel Xeon series	E3-1200

Memory

Supported memory types	DDR4-SDRAM
Supported memory clock speeds	1600,1866,2133 MHz
Number of DIMM slots	4
Maximum internal memory	64 GB
Supported DIMM module capacities	4GB,8GB,16GB
ECC
Maximum UDIMM memory	64 GB
Memory voltage	1.2 V

Storage controllers

Hard drive interface	Serial ATA III
RAID levels	0,1,5,10
RAID support

Internal I/O

USB 2.0 connectors	4
Number of SATA III connectors	6
Chassis intrusion connector
TPM connector

Back panel I/O ports

USB 2.0 ports quantity	2
USB 3.0 (3.1 Gen 1) Type-A ports quantity	2
COM ports quantity	1
Ethernet LAN (RJ-45) ports	2
IPMI LAN (RJ-45) port
VGA (D-Sub) ports quantity	1

Features

Component for	Server
Motherboard chipset	Intel C232
Motherboard form factor	microATX
Trusted Platform Module (TPM)
Trusted Platform Module (TPM) version	1.2
RoHS compliance

Networking

Ethernet LAN
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Wi-Fi

Expansion slots

PCI Express x4 (Gen 3.x) slots	1
PCI Express x8 (Gen 3.x) slots	2

Graphics

On-board graphics adapter model

Aspeed AST2400

BIOS

BIOS type	AMI
BIOS memory size	16 MB
ACPI version	4.0

Weight & dimensions

Width	240 mm (9.36 ")
Depth	240 mm (9.36 ")
