Thermaltake Smart 600W ATX power supply unit

In stock

SKU

19_PS-SPD-0600NPCWUS-W_1

Be the first to review this product

$52.00

Visit our Thermaltake Store

MPN

PS-SPD-0600NPCWUS-W

UPC

841163062241

About this item

600W, Intel ATX 12V 2.3, PFC, 50Hz - 60Hz, 100V – 240V, 120mm Fan: 1800 R.P.M. ± 10%

Description
Specifications

Thermaltake Smart 500W

Incorporating various high-quality components, the Smart Series – models are rated from 500W to 700W – saves energy through its high efficiency of up to 86% and accommodates any mainstream build with the most demanding requirements. An embedded intelligent cooling fan delivers excellent airflow at an exceptionally low noise level. Additionally, the Single +12V rail design enables non-stop usage with stable and reliable performance.

120mm Ultra Quiet Fan

Smart Series adopt 120mm cooling fan delivers excellent airflow at an exceptionally low noise level.

Multiple Connectors

Smart 500W connector’s specification as below:

80 PLUS Standard Certified and Haswell Ready

Smart Series saves energy through its high energy efficiency of up to 86% and is 80 PLUS® Standard Certified.

High-Quality Components

High quality components enable non-stop usage with stable and reliable performance, no more capacitor explosion and leakage.

Single +12V Output

Smart Series is equipped with a powerful +12V rail, superior performance under all types of system loading. Please see the output specification below:

Specifications

Power

Total power	600 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Input current	10 A
Maximum input current (@110V)	12 A
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	105 W
Combined power (+12V)	504 W
Combined power (+5V)	105 W
Combined power (-12V)	6 W
Combined power (+5Vsb)	12.5 W
Max output current (+3.3V)	22 A
Max output current (+12V)	42 A
Max output current (+5V)	17 A
Max output current (-12V)	0.5 A
Max output current (+5Vsb)	2.5 A
Hold time	16 ms
Power protection features	Over power, Short circuit
Efficiency	86 %
Power Good signal delay range	100 - 500 ms

Cooling

Fan diameter	120 mm
Fan location	Top
Cooling type	Active
Fan speed	1800 RPM
Number of fans	1 fan(s)

Ports & interfaces

Motherboard power connector	24-pin ATX
Number of SATA power connectors	8
Peripheral (Molex) power connectors (4-pin)	4
PCI Express power connectors (6+2 pin)	4
PCI Express power connectors (8-pin)	2
CPU P4 connector (4-pin)	2
CPU power connector (4+4 pin)
ATX Power connector (24-pin)
Floppy drive power connector	1
Cabling type	Modular

Performance

Purpose	PC
Power supply unit (PSU) form factor	ATX
ATX version	2.3
Mean time between failures (MTBF)	100000 h

Design

Product colour

Black

Operational conditions

Operating temperature (T-T)	5 - 40 °C
Storage temperature (T-T)	-40 - 55 °C
Operating relative humidity (H-H)	20 - 85 %
Storage relative humidity (H-H)	10 - 95 %

Weight & dimensions

Width	150 mm (5.85 ")
Depth	140 mm (5.46 ")
Height	86 mm (3.35 ")

Certificates

Safety

CE, CB, TUV, UL, FCC

Packaging content

Manual

Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for PS-SPD-0600NPCWUS-W by Thermaltake you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
