Using advanced Home Plug AV technology, TL-PA4010 KIT provides users with stable, high-speed data transfer rates of up to 600Mbps on a line length of up to 300 meters. With speed of up to 600Mbps, TL-PA4010 KIT enables heavy-bandwidth applications like HD streaming, on-line gaming and large file downloading, turning your home into a robust and high-speed networking.
Miniature Design
With its new ultra-compact housing design, TL-PA4010 KIT is much smaller than TP-Link’s legacy mini 600Mbps powerline products. At just 28.5mm thick, it nearly blends completely in front of any power outlet.
Pair Button for Easy Network Security
Simply by pushing the Pair button on the adapters, users can set up a hassle-free Powerline network within minutes, complete with 128-bit AES encryption for network security and data protection. It's that simple! 1. Plug the adapter into the power outlet 2. Connect the device via the network cable to the adapter 3. Press the pair buttons—and you're done! - HomePlug AV standard compliant, high-speed data transfer rates of up to 600Mbps1 - Miniature design, smaller than most powerline adapters at the market, blends discreetly in front of any power outlet - No new wires, Easy Plug and Play operation, No configuration required - Patented Power-Saving Mode automatically reduces power consumption by up to 85%
Specifications
Performance
Data transfer rate (max)
600
Mbit/s
Ethernet LAN
Ethernet LAN interface type
Fast Ethernet
Ethernet LAN data rates
10,100
Mbit/s
Copper ethernet cabling technology
10BASE-T,100BASE-TX
Ethernet LAN (RJ-45) ports
1
Wi-Fi
Networking standards
IEEE 802.3, IEEE 802.3u
Built-in power socket
PowerLine standard
HomePlug AV
Modulation
OFDM
Security algorithms
128-bit AES
Maximum operating distance
300
m
Encryption button
Plug and Play
Power
Power consumption (typical)
4.26
W
Power consumption (standby)
0.88
W
Design
LED indicators
Y
Product colour
White
RoHS compliance
Certification
CE, FCC
System requirements
Windows operating systems supported
Y
Mac compatibility
Linux operating systems supported
Y
Mac operating systems supported
Y
Operational conditions
Operating temperature (T-T)
0 - 40
°C
Storage temperature (T-T)
-40 - 70
°C
Operating relative humidity (H-H)
10 - 90
%
Storage relative humidity (H-H)
5 - 90
%
Weight & dimensions
Width
65
mm
(2.54 ")
Depth
52
mm
(2.03 ")
Height
28.5
mm
(1.11 ")
Packaging content
Quantity per pack
2
pc(s)
Quick installation guide
Cables included
LAN (RJ-45)
