TP-LINK TL-WR940N Single-band (2.4 GHz) Fast Ethernet wireless router

In stock

Only 1 left

SKU

6_TL-WR940N_1

Be the first to review this product

$28.00

Visit our TP-LINK Store

MPN

TL-WR940N

UPC

845973051464

About this item

450Mbps Wireless N Router

Description
Specifications

What This Product Does

450Mbps Wireless N Router TL-WR940N is a combined wired/wireless network connection device designed specifically for small business and home office networking requirements. With MIMO Technology, TL-WR940N creates an exceptional and advanced wireless performance, making it ideal for streaming HD video, making VoIP and online gaming. Also, WPS button on the sleek and fashionable exterior ensures WPA2 encryptions, preventing the network from outside intrusions.

Wireless N Speed & Range

Complying with the IEEE 802.11n standard, TL-WR940N can establish a wireless network and get up to 15X the speed and 5X the range of conventional 11g products. Also, with transmission rates up to 450Mbps, it shows more excellent abilities of mitigating data loss over long distances and through obstacles in a small office or a large apartment, even in a steel-and-concrete building. Above all, you could easily pick up the wireless network during long-distance connection where legacy 11g products may not!

Better Wireless Performance

The router has the speed to work smoothly with almost any bandwidth intensive application including VoIP, HD streaming, or online gaming, without the lag. Using its powerful N technologies, the router is also able to mitigate data loss over long distances and through obstacles turning your home and even your yard into one big hot
- spot.

WPA / WPA2 Encryptions

WPA/WPA2 encryption standards ensure your wireless connection is safe from intruders.

WPS

Instantly setup WiFi connections simply by pressing the "WPS" button.

Easy Setup

Either using the optimized user interface and setup wizard or the CD (included) setup wizard will allow you to get ‘online’ quickly and easily.

Specifications

WAN connection

Ethernet WAN

Wireless LAN features

Wi-Fi band	Single-band (2.4 GHz)
Top Wi-Fi standard	IEEE 802.11n
WLAN data transfer rate (max)	450 Mbit/s
Wi-Fi standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

Ethernet LAN features

Ethernet LAN
Ethernet LAN interface type	Fast Ethernet
Ethernet LAN data rates	10,100 Mbit/s

Ports & interfaces

USB port
Ethernet LAN (RJ-45) ports	4
DC-in jack

Mobile networking

3G
4G

Networking

Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3u
Receiver sensitivity	270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER

Protocols

DMZ support
DHCP client

Antenna

Antenna gain level (max)	5 dBi
Antennas quantity	3

Management features

Web-based management

Security

Security algorithms	128-bit WEP,64-bit WEP, SSID, WPA-PSK, WPA2-PSK
Firewall security	DoS, DDoS, NAT
VPN support	PPTP, L2TP, IPSec
MAC address filtering

Design

Product colour	Black
Indication light
LED indicators	Y

Power

Power consumption (typical)

7 W

Weight & dimensions

Width	230 mm (8.97 ")
Depth	144 mm (5.62 ")
Height	35 mm (1.37 ")

Operational conditions

Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %

Other features

Mobile network connection
xDSL connection
WLAN data transfer rates supported	450 Mbit/s
Frequency range	2.4 - 2.4835 GHz
Frequency range	2.4 - 2.4835
Rack mounting

Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for TL-WR940N by TP-LINK you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
