Tyan Tomcat HX S8030 AMD EPYC7003 Socket SP3 Max512GB DDR4 PCIE ATX
MPN
S8030GM4NE-2T
UPC
635872049507
About this item
AMD Socket SP3, 8x DIMM DDR4, 5x PCI-E Gen4 x16, 2x 10G RJ-45, 2x 1G RJ-45, IPMI, SATA, SFF-8643, VGA, USB 3.1, ATX, 305x250.8 mm
The Tyan Tomcat HX S8030GM4NE-2T is a compact server board that supports a single socket AMD EPYC 7002/7003 processor with 3D V-Cache technology
It has an ATX form factor of 12" x 9.8" and supports up to 512GB RDIMM/1,024GB LRDIMM/2,048GB LRDIMM 3DS memory.
The board has the following features:
- Memory: The board has 8 DDR4 DIMM slots (8 memory channels) supporting up to 2TB RDIMM/4TB LRDIMM/8TB LRDIMM 3DS memory.
- Storage: It has up to 14 SATA ports, 4 NVMe U.2 ports, and 2 NVMe M.2 22110/2280 slots.
- Expansion Slots: The board has 5 PCIe Gen.4 x16 slots and 2 PCIe 4.0 x8 SlimSAS connectors.
- Networking: It has 2 10GBase-T + 2 1000Base-T LAN ports and 1 dedicated 1000Base-T IPMI port.
- Graphics: The board has a D-Sub 15-pin VGA port with a resolution of up to 1920x1200 and an Aspeed AST2500 chipset.
- System Monitoring: The board has a chipset and fan that monitor temperature for CPU, memory, and system environment, as well as voltage for CPU, memory, chipset, and power supply.
- Operating System: The board supports Windows Server 2019 V1809, RHEL 7.6/7.7/8.0, Ubuntu DeskTop 19.04, and CentOS 7.6/7.7.
- TPM Module Compatibility: The board is compatible with TPM modules.
The Tyan Tomcat HX S8030GM4NE-2T is a powerful and versatile server board suitable for a wide range of applications.
Specifications
Processor
| Processor socket | Socket SP3 |
| Processor manufacturer | AMD |
| Compatible processor series | AMD EPYC |
| Number of processors supported | 1 |
Memory
| Supported memory types | DDR4-SDRAM |
| Supported memory clock speeds | 3200 MHz |
| Number of DIMM slots | 8 |
| Maximum internal memory | 2048 GB |
| Memory channels | Octa-channel |
| Memory voltage | 1.2 V |
Storage controllers
| Hard drive interface | Serial ATA III |
Internal I/O
| Number of SATA III connectors | 2 |
| ATX Power connector (24-pin) | |
| Number of chassis fan connectors | 4 |
| Number of COM connectors | 1 |
Back panel I/O ports
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| IPMI LAN (RJ-45) port | |
| Ethernet LAN (RJ-45) ports | 4 |
| VGA (D-Sub) ports quantity | 1 |
Features
| Component for | Server |
| Motherboard form factor | ATX |
| RoHS compliance |
Networking
| Ethernet LAN | |
| Ethernet interface type | 10 Gigabit Ethernet, Gigabit Ethernet |
| LAN controller | Intel I210-AT, Intel X550-BT2, Realtek RTL8211E |
| Wi-Fi |
Expansion slots
| PCI Express x16 slots | 5 |
Graphics
| On-board graphics adapter model | Aspeed AST2500 |
BIOS
| BIOS type | AMI |
| BIOS memory size | 32 MB |
| ACPI version | 6.2 |
| System management BIOS (SMBIOS) version | 3.2 |
Operational conditions
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
| Storage relative humidity (H-H) | 0 - 90 % |
Weight & dimensions
| Width | 305 mm (11.9 ") |
| Depth | 250.8 mm (9.78 ") |
Packaging content
| Cables included | SATA |
