Zebra CS60 Handheld bar code reader 1D/2D LED BK
MPN
CS6080-SRK0004VZWW
About this item
Corded CS60 Companion Scanner, Circular 525nm true green LED, 1280 x 960 pixels, Bluetooth 5.0 BLE
Ultra-versatile with a First-of-ITS-KIND Convertible Design
The ultra-versatile CS60 Series Companion Scanner adapts to any workflow.
Its groundbreaking design easily converts between corded and cordless operation, handheld and hands-free, as your needs for superior investment protection change.
ADAPTS TO ANY WORKFLOW
As a cordless companion scanner, the CS60 is small enough to tuck into a pocket or wear on a lanyard.
And as a corded scanner, the CS60 offers compact handheld or hands-free scanning for the checkout counter, self-service kiosk, and more.
Whether you purchase a corded or cordless model up front, you can change modes at any time.
CUTTING-EDGE MOBILITY
With Qi inductive charging, split-second NFC tap-to-pair, Bluetooth 5.0 with Wi-Fi friendly mode, an 18-hour battery, and Virtual Tether anti-loss functionality, the cordless CS60 is pocketable and wearable when mobility is essential.
EASY TO SET UP AND MANAGE
DataCapture DNA is a unique collection of value-add tools that make it easier to deploy, update, troubleshoot, manage, and develop applications for your business.
Specifications
Scanning
| Optical sensor resolution (W x H) | 1280 x 960 pixels |
| Scanner type | 1D/2D |
| Sensor type | LED |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar, MSI, Plessey, U.P.C. |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39 |
| Wavelength | 525 nm |
| Tilt reading angle | -60 - 60 ° |
| Pitch reading angle | -60 - 60 ° |
| Yaw reading angle | 0 - 360 ° |
| Light levels (direct sunlight) | 0 - 108000 lx |
Ports & interfaces
| Connectivity technology | Wireless |
| Standard interfaces | Bluetooth, USB |
| Wireless range | 100 m |
| Bluetooth version | 5.0 |
Design
| Type | Handheld bar code reader |
| International Protection (IP) code | IP65 |
| LED indicators | Y |
| Product colour | Black |
| RoHS compliance |
Power
| Power source type | AC, DC, USB |
| Number of reads per charge | 13000 |
| Power consumption | 400 mA |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
| Operating relative humidity (H-H) | 5 - 95 % |
Weight & dimensions
| Width | 46 mm (1.79 ") |
| Depth | 109 mm (4.25 ") |
| Height | 23 mm (0.9 ") |
| Weight | 56 g (0.12 lbs) |
Other features
| Y |
