Aten VS192 DisplayPort video splitter
Eligible for Free Shipping & Free Returns
MPN
VS192
UPC
672792007200
About this item
2 x DisplayPort, VDC, 0.3 kg, HBR2
The VS192 2-Port 4K DisplayPort Splitter is the perfect solution for anyone who needs to send one source of DisplayPort high definition video to two or four DisplayPort displays. The VS192 can not only split but also expand DisplayPort audio/video signal on two or four DisplayPort monitors which is ideal for any multi-display application.
The VS192 is compatible with DisplayPort 1.2a and can support up to 4K resolution at 60 Hz, making it effective and ideal for use with all DisplayPort displays in home theater applications, as well as in corporate, educational and commercial settings.
- Connects one DisplayPort source to two or four DisplayPort monitors
- Supports DisplayPort 1.2a; HDCP 1.3
- Supports resolutions up to 4096 x 2160 / 3840 x 2160 @ 60 Hz
- Supports MST/ Extend Mode and SST/ Split Mode*
- MST/ Extend Mode:
- Extend a video source across 2 displays with a maximum resolution of 4K.
- SST/ Split Mode:
- Duplicate a single video source to 2 displays with a maximum resolution of 4K on each monitor
- Supports Linkrate: HBR2 (High Bit Rate 2)
The VS192 is compatible with DisplayPort 1.2a and can support up to 4K resolution at 60 Hz, making it effective and ideal for use with all DisplayPort displays in home theater applications, as well as in corporate, educational and commercial settings.
- Connects one DisplayPort source to two or four DisplayPort monitors
- Supports DisplayPort 1.2a; HDCP 1.3
- Supports resolutions up to 4096 x 2160 / 3840 x 2160 @ 60 Hz
- Supports MST/ Extend Mode and SST/ Split Mode*
- MST/ Extend Mode:
- Extend a video source across 2 displays with a maximum resolution of 4K.
- SST/ Split Mode:
- Duplicate a single video source to 2 displays with a maximum resolution of 4K on each monitor
- Supports Linkrate: HBR2 (High Bit Rate 2)
Specifications
Ports & interfaces
| Video ports quantity | 2 |
| Video port type | DisplayPort |
| DC-in jack |
Video
| Supported graphics resolutions | 3840 x 2160,4096 x 2160 |
| Maximum resolution | 4096 x 2160 pixels |
| Full HD | |
| HD-Ready | |
| HDCP |
Colour
| Product colour | Black |
Power
| Power consumption (typical) | 1.185 W |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 0 - 80 % |
Technical details
| Colour | |
| Housing material | Metal |
Weight & dimensions
| Weight | 300 g (0.66 lbs) |
| Dimensions (WxDxH) | 125 x 80 x 250 mm |
Packaging content
| User guide | |
| Manual |
Logistics data
| Quantity per master carton | 20 pc(s) |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
VS192 by Aten
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
