Axis P7304 video servers/encoder 1920 x 1080 pixels 30 fps

SKU

1_01680-001_1

Be the first to review this product

$456.00

Visit our Axis Store

MPN

01680-001

UPC

7331021066403

AXIS P7304 Video Encoder

With AXIS P7304 Video Encoder you can migrate to IP surveillance at your own pace. Including the latest generation of Axis chip, it supports HD analog cameras and provides a high level of defense to protect your system. Plus, Zipstream and support for H.264/H.265 reduces bandwidth and storage requirements, while preserving high image quality.

Everything you need and more

AXIS P7304 is a full-featured four-channel video encoder with great video performance. This encoder supports HD analog (high definition TVI, high definition CVI and analog HD) and standard resolution analog cameras. It offers support for two-way audio and intelligent analytics such as motion detection, as well as audio detection with analog and digital AXIS T83 microphones. It features RS-485/422 for controlling analog PTZ (pan/tilt/zoom) cameras. It provides edge storage through a microSDHC memory card slot. And, thanks to configurable input/outputs you can connect external devices such as sensors, relays and speakers to activate lights, open/close doors and trigger audio clips.

Seamless migration to IP surveillance

Axis video encoders allows you to migrate to the world of IP surveillance while protecting your investment in analog equipment, so you get to keep all your existing cameras and cabling. And, thanks to support for Power over Ethernet (PoE) you can connect directly to your IP network with just one network cable for connectivity and power. Furthermore, this flexible solution lets you choose between saving the recordings on a server, on the edge or in the cloud.

First-class Axis Quality

Like all Axis products, AXIS P7304 is built on an open platform so you're free to use open-standard hardware or software from the supplier of your choice. Signed firmware and secure boot guarantees that the firmware hasn't been altered and only authorized firmware is installed. And with on-going firmware upgrades, you can depend on Axis first-class quality and support all the way. Plus, Zipstream with support for H.264/H.265 video compression significantly reduces bandwidth and storage requirements without compromising image quality.
- Support for HD analog cameras
- Extended capacity for analytics
- Zipstream with support for H.264/H.265
- Signed firmware and secure boot
- PoE, I/O, audio and PTZ support

Specifications

Video

Maximum video resolution	1920 x 1080 pixels
Maximum frame rate	30 fps
Video compression formats	AVC, H.264, H.265, HEVC, MPEG4
NTSC resolutions	720x480 pixels
PAL resolutions	720x576 pixels
Channels quantity	4 channels

Technical details

Image settings	Brightness, Color, Compression, Contrast, Mirroring, Privacy mask, Rotation, Sharpness
Internal memory	1024 MB
Flash memory	512 MB
PTZ control (Pan/Tilt/Zoom)
Product colour	Grey
Wall mountable

Security

Audio detection
Video motion detection
IP address filtering
Active tampering alarm
Security algorithms	HTTPS

Networking

Copper ethernet cabling technology	10BASE-T,100BASE-T,1000BASE-T
Power over Ethernet (PoE)
Networking standards	IEEE 802.3af, IEEE 802.3at
Supported network protocols	IPv4, IPv6 USGv6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH
Quality of Service (QoS) support

Ports & interfaces

RS-485 ports	2
I/O terminal ports	1
Line-in
BNC input ports	4
Ethernet LAN (RJ-45) ports	1
Microphone in
Line-out

Features

Card reader integrated
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC

Weight & dimensions

Width	187 mm (7.29 ")
Height	37 mm (1.44 ")
Weight	650 g (1.43 lbs)

Indication

LED indicators

Status

Operational conditions

Storage temperature (T-T)	-40 - 65 °C
Operating relative humidity (H-H)	10 - 85 %
Operating temperature (T-T)	0 - 50 °C

Power

Power consumption (typical)

8.2 W

Packaging content

Manual

Certificates

Certification

EMC EN 55032 Class A, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KC KN35, IEC/EN 62368-1, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, NIST SP500-267
