Supermicro SuperServer E200-8D 1U Mini Server
SKU
19_SYS-E200-8D_1
Special Price
$964.19
Regular Price
$1,283.00
MPN
SYS-E200-8D
UPC
672042243907
About this item
- Mini-1U;
- Intel Xeon processor D-1528, Single socket FCBGA 1667;
- M.2 PCI-E 3.0 x4 (SATA support) M Key 2242/2280;
- 2 x 10 GbE, 2 x GbE LAN ports & dedicated LAN for IPMI 2.0;
- Aspeed AST2400, SoC, 6x SATA III, VGA, USB 3.0, SuperDOM;
- DC power adapter;
E200-8D SuperServer from Supermicro (SKU Model: SYS-E200-8D)
Supermicro SuperServer SYS-E200-8D system is equipped with an Intel Xeon D-1528 6-Core Processor with two 10GBase-T LAN ports for transferring data at up to 10GB/sec.
Supermicro's outstanding track record and competitive advantages have made it a top player in the high-end server and storage market.
With the broadest range of products in the industry, Supermicro offers Atom, dual Xeon® and quad Xeon®MP systems.
Supermicro SuperServer E200-8D 1U Mini PC Server are the platform of choice for HPC, enterprise, cloud, data center, hyperscale, embedded, and business-critical, front-end server applications because of their high level of quality and performance.
It is ideal for embedded network applications, virtualization servers, firewall applications and network security appliances thanks to its high performance and features in a Mini-1U form factor.
The system comes with an Intel Xeon D-1528 processor (6 cores, 12 threads) loaded into a BGA socket. It also has four DIMM slots that can accommodate up to 128GB of DDR4 memory with ECC.
As well as a 2.5" drive bay, this server incorporates two 10GbE ports, two GbE ports, an M.2 PCIe 3.0 x4 connector (supporting SATA and PCIe), and two 10GbE ports.
It is easier to keep computers stable and reliable when they have external AC power adapters, since they do not build up heat inside a power supply.
A storage drive, system memory, and the Operating System software are needed to complete this system.
SuperServers are Your Best Choice!
SuperServer Benefits:
- Uncompromising Quality Control;
- The most Comprehensive Line of Servers, Storage Systems, and Subsystems;
- Widest Variety of Application Optimized Solutions, from High End Clusters to MicroServers;
- Best Performance per-Watt, per-Square-Foot, and per-Dollar;
- Consistently First-to-Market;
- Best Total Cost of Ownership (TCO);
- Highest Quality Components and Materials;
- Redfish API support;
Specifications
Processor
| Processor frequency | 1.90 GHz |
| Processor family | Intel Xeon D |
| Processor model | D-1528 |
| Processor cores | 6 |
| Number of processors installed | 1 |
| Processor cache type | L3 |
| Processor cache | 9 MB |
| Thermal Monitoring Technologies | |
| Memory clock speeds supported by processor | 1600,1866,2133 MHz |
| Stepping | V2 |
| Thermal Design Power (TDP) | 35 W |
| Processor socket | BGA 1667 |
| Maximum number of PCI Express lanes | 32 |
| Processor codename | Broadwell |
| Memory channels supported by processor | Dual |
| Processor boost frequency | 2.50 GHz |
| PCI Express configurations | 1x16,1x4,1x8 |
| Processor series | Intel Xeon D-1500 |
| ECC supported by processor | |
| Processor package size | 37.5 x 37.5 mm |
| Memory voltage supported by processor | 1.2 V |
| Processor lithography | 14 nm |
| Supported instruction sets | AVX 2.0 |
| Execute Disable Bit | |
| Maximum internal memory supported by processor | 128 GB |
| Processor threads | 12 |
| Scalability | 1S |
| Idle States | |
| Processor operating modes | 64-bit |
| Embedded options available | |
| Memory types supported by processor | DDR3-SDRAM, DDR4-SDRAM |
| Conflict Free processor |
Memory
| Flash memory | 128 MB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 128 GB |
| Memory slots | 4 |
Storage
| Supported hard disk drive sizes | 2.5 " |
| Supported storage drive interfaces | M.2, Serial ATA III |
Networking
| LAN controller | Intel I350AM2, Realtek RTL8201N |
| Ethernet LAN | |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | 10 Gigabit Ethernet, Gigabit Ethernet |
Ports & interfaces
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| Total number of SATA connectors | 6 |
| VGA (D-Sub) ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| Number of SATA III connectors | 6 |
Expansion slots
| PCI Express slots version | 2.0,3.0 |
Design
| Chassis type | Mini (1U) |
| Optical drive type | N |
| Motherboard form factor | Mini ITX |
Performance
| Trusted Platform Module (TPM) | |
| Trusted Platform Module (TPM) version | 2.0 |
| BIOS type | AMI |
Processor special features
| Intel Enhanced Halt State | |
| Intelligent Platform Management Interface (IPMI) support | |
| Intel VT-x with Extended Page Tables (EPT) | |
| Enhanced Intel SpeedStep Technology | |
| CPU configuration (max) | 1 |
| Intel 64 | |
| Intel Virtualization Technology for Directed I/O (VT-d) | |
| Intel® Secure Key | |
| Intel® Hyper Threading Technology (Intel® HT Technology) | |
| Intel Virtualization Technology (VT-x) | |
| Intel TSX-NI | |
| Intel® Turbo Boost Technology | 2.0 |
| UART | |
| Intel® OS Guard | |
| Intel® AES New Instructions (Intel® AES-NI) | |
| Processor ARK ID | 91198 |
| Intel Trusted Execution Technology |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 8 - 90 % |
| Storage relative humidity (H-H) | 5 - 95 % |
Certificates
| Certification | RoHS |
Weight & dimensions
| Width | 193 mm (7.53 ") |
| Depth | 226 mm (8.81 ") |
| Height | 43 mm (1.68 ") |
| Weight | 1360 g (3 lbs) |
Packaging data
| Package width | 381 mm |
| Package depth | 142 mm |
| Package height | 276 mm |
| Package weight | 2950 g |
Packaging content
| Heat sink included |
Technical details
| Number of 2.5" bays | 1 |
Other features
| Power management | |
| Graphics adapter | AST2400 |
