President Lincolnii+ Am/Fm/Lsb/Usb/Cw 10/12 Meter 50 Wat

Experience the joy of amateur radio with the new and improved President Lincoln II Plus amateur radio. It features enhanced echo and power output.

The President Electronics® brand name is well known in the CB radio world.

President Electronics represents an association of pure CB users and amateurs who are interested in technology.

Same as Lincoln II but with a 12 meter band, emergency channels 1 and 2 programmable by user; 35W PEP SSB instead of 31W PEP SSB, 35W FM instead of 28W; 12W RMS 48WPEP.

Up/down channel selection; Volume adjustment; Manual squelch; ASC; RF power; MENU function key; Dim; Mode switch AM/FM/LSB/USB/CW.

VFO Mode with continuous scanning, Multi-function LCD display, Frequency display, S-meter, Channel and memory scanning, 6 Memories, CTCSS (38 tones), and DCS (104 codes).

President Lincoln II Plus 10 and 12 Meter Ham Radio unit features a Public Address system, Vox function (hands-free), ANL filter, NB and HI-CUT, RF gain / Mic gain, Clarifier and Roger Beep as well as an external loudspeaker jack.

Dual watch; Key locking; SWR (Power Reading/SWR); Preset emergency (EMG 1/2); TOT (Time Out Timer) adjustable.

Specifications:

• Modulation modes: AM/FM/LSB/USB/CW
• Frequency ranges: continuous scanning of 24.890 Mhz to 24.990 Mhz and of 28.000 Mhz to 29.700 Mhz
• Antenna impedance: 50 ohms
• Power supply: 13.8 V
• Size (WxDxH): 6.69" x 9.84" x 2.05"
• Weight: 3.09 lb
• Accessories supplied: power cord with fuse, 1 microphone and its hanger, 1 mounting bracket with fixing screws
• Frequency allowance: +/- 300 Hz
• Carrier power: 50 W AM (PEP) / 35 W FM / 35W USB-LSB (PEP) / 12W CW
• Transmission interference: inferior to -50 dBc
• Audio response: 300 Hz to 3 kHz
• Microphone sensitivity: 3 mV
• Modulated signal distortion: 1.8 %
• Squelch sensitivity: minimum 0.2 μV - 120 dBm, maximum 1 mV - 47 dBm
• Emitted power in the adj. channel: inferior to 20 µW
• Microphone Plug: Front (6 pins)
