Telewave ANT150F6-4 television antenna Outdoor Omni-directional 6 dB
MPN
ANT150F6-4
About this item
Omnidirectional Collinear Antenna, 156 - 164 MHz, 500 Watt, N Female
The Telewave ANT150F6 SERIES
- Omnidirectional Collinear Antenna 138-175 MHz, is an extremely rugged, medium-gain, fiberglass collinear antenna, designed for operation in all environmental conditions. The antenna is constructed with brass and copper elements, connected at DC ground potential for lightning impulse protection. All junctions are fully soldered to prevent RF intermodulation, and each antenna is completely protected within a high-tech, flexible radome to ensure survivability in the worst environments.
The ANT150F6 includes an ANTC482 dual clamp set for mounting to a 1.5” to 3.5” O.D. support pipe, and a 24” removable RG-213 N-Male jumper. Stand-off and top mounts are also available.
- Omnidirectional Collinear Antenna 138-175 MHz, is an extremely rugged, medium-gain, fiberglass collinear antenna, designed for operation in all environmental conditions. The antenna is constructed with brass and copper elements, connected at DC ground potential for lightning impulse protection. All junctions are fully soldered to prevent RF intermodulation, and each antenna is completely protected within a high-tech, flexible radome to ensure survivability in the worst environments.
The ANT150F6 includes an ANTC482 dual clamp set for mounting to a 1.5” to 3.5” O.D. support pipe, and a 24” removable RG-213 N-Male jumper. Stand-off and top mounts are also available.
Specifications
Features
| Placement | Outdoor |
| Antenna type | Omni-directional |
| Product colour | White |
| Material | Fiberglass |
| Gain | 6 dB |
| Connector(s) | N-Type |
| Vertical beam width | 20 u00b0 |
| Supported radio bands | VHF |
| Connector gender | Female connector |
| Reception range (VHF) | 156 - 164 MHz |
| Impedance | 50 Ω |
Power
| Power | 500 W |
Weight & dimensions
| Height | 6197.6 mm (241.71 ") |
| Weight | 18597 g (41 lbs) |
| Diameter | 69.85 mm |
Packaging data
| Quantity | 1 |
| Package weight | 28122 g |
