Tripp Lite HDMI Signal Booster/Extender Cable, 1920x1200 at 24Hz/1080p (HDMI M/F), 1-ft.

MPN
B123-001
UPC
037332141057

About this item
HDMI Signal Booster/Extender Cable, 1920x1200 at 24Hz/1080p (HDMI M/F), 1-ft.
Tripp Lite's B123-001 HDMI Signal Extender increases the distance a 1080p @ 24Hz (or 1920 x 1200) signal can be transmitted beyond the recommended 16 ft. (5 m.). It supports computer video resolutions up to 1920 x 1200, and HD resolutions up to 1080p @ 24Hz, at a maximum distance of 46 m (150-ft.) from the source. Use P568-Series HDMI cables in most applications. When extending a 1080p @ 24Hz (or 1920 x 1200) signal more than 23 m (75-ft.), use cable made with 24Awg wiring, such as the P568-100-HD. (Lengths over 30.5 m (100-ft.) are available from Tripp Lite as a custom order) 24Awg HDMI cable is also needed when extending a 3D signal more than 15 m (50-ft.). A 3D signal can be extended up to 38 m (125-ft.) using 24Awg HDMI cable. Simply connect the longer cable between the source and the B123-001, and then connect the built-in cable to the monitor. Software or drivers are not required. HDCP compliant.
● Extend a 1080p @ 24Hz (or 1920 x 1200) HDMI signal up to 46 m (150-ft.) from the source
● Use P568-Series HDMI cables in most applications
● When extending a 1080p @ 24Hz (or 1920 x 1200) signal more than 23 m (75-ft.), use cable made with 24Awg wiring, such as the P568-100-HD. (Lengths over 30.5 m (100-ft.) are available from Tripp Lite as a custom order)
● 24Awg HDMI cable is also needed when extending a 3D signal more than 15.24 m (50-ft.) A 3D signal can be extended up to 38 m (125-ft.) using 24Awg HDMI cable
● Supports DTS-HD, Dolby True HD and 7.1 Channel Surround Sound Audio
● HDCP compliant
● No software or drivers required
Specifications
Features
Type AV repeater
Maximum resolution 1920 x 1200 pixels
Cable types supported Cat5, Cat5e
Maximum transfer distance 45.72 m
Cable length 0.3 m
Supported video modes 1080p
Product colour Black
RoHS compliance
Ports & interfaces
HDMI in 1
Number of HDMI outputs 1
Technical details
Connector 2 HDMI
Quantity 1
Connector 1 HDMI
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for B123-001 by Tripp Lite you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
