Tripp Lite MTP/MPO Patch Cable with Push/Pull Tabs, 12 Fiber, 40GbE, 40GBASE-SR4, OM3 Plenum-Rated - Aqua, 3M

In stock
Only 4 left
SKU
6_N844-03M-12-P_1
$192.00
Eligible for Free Shipping & Free Returns
MPN
N844-03M-12-P
UPC
037332173737
About this item
MTP/MPO Patch Cable with Push/Pull Tabs, 12 Fiber, 40GbE, 40GBASE-SR4, OM3 Plenum-Rated - Aqua, 3M
Tripp Lite MTP/MPO to MTP/MPO fiber patch cables allow high-density connections between network equipment in telecommunication rooms and data centers. They feature Push/Pull tab connectors that offer maximum accessibility in high density installations; install / remove with one hand. The MTP/MPO connector is approximately the same size of a SC connector but since it can accommodate 12 fibers, it provides up to 12 times the density, thereby offering savings in circuit card and rack space. N844 series cables are manufactured using laser-optimized, 50/125, OM3 multimode cable, and support speeds up to 40GbE.
● MTP / MPO Push-Pull Connectors for Quick Fiber Optic connections
● Push/Pull tab connectors offer maximum accessibility in high density installations; install / remove with one hand
● 12 times the density of SC style connectors
● High Density design cuts down on installation costs
● 50/125 OM3 Rated Multimode Fiber, 850nm
● Plenum rated jacket
● Unique cable ID label for Quality Control and Traceability
● Each cable 100% tested for low insertion loss and back reflection
● Test data supplied with each cable
● Custom lengths available
● Hi-density MTP/MPO 12-fiber connectors for reduced cabling
● Push/Pull tab connectors offer maximum accessibility in high density installations; install / remove with one hand
● OM3 rated 50/125 Multimode
● Supports to 40GbE speeds

Package Includes

● 3 Meter MTP / MPO Patch Cable, 12 Fiber, 40GbE Aqua OM3 Plenum
Specifications
Features
Cable length 3.05 m
Connector 1 MTP
Connector 2 MTP
Fiber optic type OM3
Cable colour Black, Turquoise
Core diameter 50 µm
Cladding diameter 125 µm
Fiber mode structure Multi-mode
Data transfer rate 40 Gbit/s
Gender Male connector/Male connector
Wavelength 850 nm
RoHS compliance
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for N844-03M-12-P by Tripp Lite you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
