Tripp Lite NPOEI PoE Injector

SKU

9_NPOEI-90W-1G_1

Be the first to review this product

$271.00

Visit our Tripp Lite Store

MPN

NPOEI-90W-1G

UPC

037332265920

Tripp Lite NPOEI PoE Injector injector lets you send Gigabit Ethernet data and 90W of power through existing Cat5e/6/6a cabling without the need for an expensive upgrade to a PoE switch.

The material is recommended for outdoor applications including LED lights, surveillance cameras, and heater elements.

Avoids unnecessarily upgrading equipment

Utilizing existing Cat5e/6/6a cables, this Tripp Lite NPOEI PoE Injector delivers data at 10/100/1000 Mbps (1 Gbps) and power at 90W.

So, in addition to not having to purchase a new PoE network switch, you will also not have to install a new AC power line or electrical outlet.

Injectors like this reduce cable clutter, equipment costs, installation time, and installation labor by transmitting DC power and Ethernet data over an Ethernet cable.

You can extend your PoE network up to 328 feet

The NPOEI-90W-1G delivers power and data up to 328 feet (100 meters) away to any IEEE 802.3af (PoE), 802.3at (PoE+) or 802.3bt (4PPoE) device.

It is also possible to install a device on a ceiling, in a warehouse, or anywhere else that an AC power outlet cannot be found.

With the PoE+ injector, you can send and receive data simultaneously at 2 Gbps in full-duplex mode.

Additionally, it protects your device from short circuits, high voltage and overloads.

Quick Plug-and-Play Installation Has Your Device Connected in Minutes

Installing the NPOEI-90W-1G on your LAN (local area network) requires no configuration or software.

Use your Cat5e/6/6a cable to connect the shielded RJ45 LAN port of your switch or Ethernet network to the shielded RJ45 PoE port of your PoE device.

The terminal block includes dual primary and redundant power inputs. Your application's settings can be found with the aid of DIP switches and LEDs.

It automatically detects which connected devices are compatible with the NPOEI-90W-1G.

Designed for mounting on a DIN rail

For mounting the metal IP30 housing on a corrosion-free rail, a DIN rail kit is included. Thanks to its silent operation, the housing is designed without a fan.

Specifications

Networking

Ethernet interface type	Gigabit Ethernet
Ethernet LAN data rates	1000 Mbit/s
Networking standards	IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt

Features

Wall mountable
Rack mounting
Product colour	Black
LED indicators	Y
Country of origin	Taiwan

Power

Input voltage	24 - 57 V
Input frequency	50/60 Hz
Total Power over Ethernet (PoE) budget	90 W

Operational conditions

Operating temperature (T-T)	-40 - 75 °C
Operating temperature (T-T)	-49 - 167 °F
Operating relative humidity (H-H)	5 - 95 %
Storage temperature (T-T)	-40 - 85 °C
Storage relative humidity (H-H)	5 - 95 %

Weight & dimensions

Width	25 mm (0.98 ")
Depth	100 mm (3.9 ")
Height	116 mm (4.52 ")

Packaging data

Package width	232.9 mm
Package depth	182.9 mm
Package height	62 mm
Package weight	370 g

Logistics data

Master carton width	384 mm
Master carton length	334 mm
Master carton height	260.1 mm
Master carton weight	4500 g
Quantity per master carton	10 pc(s)

Other features

	Y
	CE, REACH, RoHS
	10037332265927
