Vaddio EasyIP 10 2.38 MP White 1920 x 1080 pixels 60 fps CMOS 25.4 / 2.8 mm (1 / 2.8")

Out of stock
SKU
9_999-30200-000W_1
$3,042.00
MPN
999-30200-000W
UPC
840077505950

About this item
2.14 MP, 10x, 1080p, 60, PoE+, 155 x 145 x 163 mm, 1.36 kg, White

EasyIP 10 Camera


The EasyIP 10 Camera is an integral part of the EasyIP Ecosystem, an AV-over-IP solution for videoconferencing in small, medium and large conference rooms. It sends 1080p/60 resolution feeds to the EasyIP Ecosystem for delivery to UC soft clients and connects to a 1 GB PoE+ switch – eliminating the need for costly USB extensions. The PoE+ powered EasyIP 10 Camera is optimized to work with the Luxul AMS-1208P Managed PoE Switch; it also works with other properly configured 1 GB PoE switches.

New! Vaddio Deployment Tool


Simplify installations by viewing all your Vaddio products across a deployment on one screen with the simple click of a button. The Vaddio Deployment Tool enables you to select devices from the network, choose an action like rebooting the device, unmute the audio, or updating firmware and voilà! – remote troubleshooting success. You can even conduct mass firmware updates on hundreds of devices all at once, which saves you a lot of time.

The EasyIP 10 Camera is an integral part of the EasyIP Ecosystem, an AV-over-IP solution for videoconferencing in small, medium and large conference rooms. It delivers 1080p/60 resolution feeds for UC soft clients and connects to a 1 GB PoE+ switch – eliminating the need for costly USB extensions.

The EasyIP 10 Camera delivers high definition imaging, exceptional color reproduction and fine detail. With a 67-degree wide horizontal field of view and 10x optical zoom, EasyIP 10 Camera, as part of the EasyIP Ecosystem, is ideal for meeting spaces in corporate, healthcare, government and education environments.

This Package Includes:

- EasyIP 10 Camera (black or white)
- Thin Profile Wall Mount with mounting hardware and installation guide
- Vaddio IR Remote Commander
- 10 ft (3.05m) cat-5e snagless Cable, black
- Quick-Start Guide
Specifications
Camera
Megapixel 2.38 MP
Sensor type CMOS
Optical sensor size 1/2.8 "
Effective sensor resolution 2.14 MP
Optical zoom 10 x
Focal length range (f-f) 3.8 - 38 mm
Horizontal field of view (wide) 67 u00b0
Horizontal field of view (tele) 7.6 u00b0
Minimum illumination 100 lx
White balance Auto, Manual, One push
Signal-to-Noise Ratio (SNR) 50 dB
Auto focusing (AF) modes Auto, Manual
Wide Dynamic Range (WDR)
Number of camera presets 16
Back Light Compensation (BLC)
Aperture number of steps 16
Gain control type Auto/Manual
Aspect ratio 3:2,4:3,16:9
PTZ control (Pan/Tilt/Zoom)
Aperture range (F-F) 1.8 - 3.4
Minimum working distance (wide) 10 mm
Video
HD type Full HD
Maximum video resolution 1920 x 1080 pixels
Maximum frame rate 60 fps
Resolution at capture speed 1280x720@50fps,1280x720@59.94fps,1280x720@60fps,1920x1080@25fps,1920x1080@29.97fps,1920x1080@50fps,1920x1080@59.94fps,1920x1080@60fps
Supported video modes 720p,1080i,1080p
Design
Product colour White
Mounting type Stand
Tilt angle range -30 - 90 u00b0
Pan range -165 - 165 u00b0
Web-based management
Tilt speed (max) 90 °/sec
Pan speed (max) 90 °/sec
Ports & interfaces
Power over Ethernet plus (PoE+) ports quantity 1
Ethernet LAN (RJ-45) ports 1
Power
Power source type PoE
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 20 - 80 %
Performance
Remote control function
Audio
Noise reduction
Packaging content
Cables included Serial
Mounting kit
Quick start guide
Weight & dimensions
Width 155 mm (6.05 ")
Depth 145 mm (5.66 ")
Height 163 mm (6.36 ")
Weight 1360 g (3 lbs)
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for 999-30200-000W by Vaddio you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
