Vigitron MaxiiPower 8 port PoE UTP Ethernet Extender VI2508
About this item
- High power midspan with built-in Ethernet extender for distances up to 3,000 feet (914 m);
- 8 port of IEEE 802.3 af/at compliant up to 37W per port simultaneously on all ports with no power management required;
- Ports 1-4 can provide 74W each;
- Provides full .af (12.95W) up to 3,000 ft./914 m and full .at (25.4W) up to 800 ft./ 243 m;
- Can provide 100Mbps data and 74W PoE for IP cameras with heaters, blowers, and high speed PTZ operation;
- Fully mananageable with Windows GUI accessible through local USB port or network connection with default plug-and-play option;
MaxiiPower Vi2508 UTP Ethernet Extender feature extended range for the most demanding PoE and IP camera demands.
The ports can provide up to 36W each without power sharing, and they are fully manageable.
With Vigitron's unique Symmetric Bandwidth (SBW) technology, the MaxiiPower Vi2508 series provides extended distance transmission over UTP.
Vigitron Vi2508 can provide full 802.3.af & 802.3at on all ports with just a transceiver and no additional power supply.
In addition, a single port can supply 74W of power for high power applications such as PTZ cameras.
They require no IP settings or configurations, and are fully transparent to the Ethernet network and higher layer protocols. The PoE controllers are auto-configured and require no programming.
Managed through an intuitive Windows-based GUI that can be accessed via a direct USB connection or remotely on the network, the PoE is fully manageable.
Vigitron MaxiiPower 8-port PoE UTP Ethernet Extender can also be operated automatically without the need for programming.
All Vigitron Midspans' set ups can be discovered with the accessory client software, and individual ports can be monitored.
By eliminating the need for standard PoE midspans with obvious limitations in power and protection, the Ethernet extender technology simplifies the installation and lowers the cost of the system.
Midspans from MaxiiPower have LEDs that show the status of power and transmission to indicate potential problems.
Managing the PoE is easy with a GUI that can be accessed directly through a USB port, or remotely via a network connection.
Specifications
Performance
| Type | Network transmitter |
| Maximum transfer distance | 914 m |
| Power over Ethernet (PoE) | |
| Data transfer rate | 100 Mbit/s |
| Cable types supported | Cat5 |
Networking
| Cabling technology | 10/100Base-T(X) |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 16 |
Design
| Product colour | Black |
| LED indicators | Y |
| On/off switch |
Power
| AC input voltage | 90-264 V |
| AC input frequency | 50/60 Hz |
| Input current | 6.5 A |
| Power consumption (typical) | 300 W |
| External power adapter |
Operational conditions
| Operating temperature (T-T) | -10 - 50 °C |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
Weight & dimensions
| Width | 430 mm (16.77 ") |
| Depth | 305 mm (11.9 ") |
| Height | 43 mm (1.68 ") |
| Weight | 4080 g (8.99 lbs) |
