Vivotek ND8301 Digital Video Recorder
MPN
ND8301
UPC
4712123672625
About this item
- Dual-core Intel processor;
- 2GB DDRIII;
- Windows 7 embedded;
- 2 x 8.89 cm (3.5") HDD;
- VGA, Ethernet, USB 2.0, eSATA, 2.27 kg;
VIVOTEK ND8301 is an 8-channel Network Video Recorder. Its built-in Intel dual-core processor delivers maximum recording throughput of 96 Mbps
A first desktop type for the VIVOTEK NVR series, a local display output port is now available with full HD resolution (1920X1080), eliminating the need for a separate PC to view video from the unit.
Setup of parameters such as IP, HDD, and basic camera configuration can easily be performed with the setup wizard, making the ND8301 the easiest NVR to use yet.
With so many different types of cameras and video recording devices on the market today, it's important to have a type of NVR that is easy to use.
With the new VIVOTEK ND8301, users can set up their camera's IP address, HDD location, and basic camera functionality with the setup wizard.
As VIVOTEK's recording features are integrated into VAST, cutting-edge technologies such as Activity Adaptive Recording can be utilized to conserve bandwidth and optimize recording.
A CMS server running VAST software can also directly control the ND8301, and compatibility with the iViewer application allows for remote access to the ND8301 on handheld devices.
By integrating all of the components together using VIVOTEK's ND8301, network cameras, VAST and iViewer software, users can realize a fully-featured and robust next-generation surveillance system.
Specifications
Performance
| Video compression formats | H.264, M-JPEG, MPEG4 |
| Audio formats supported | AAC, AMR |
| Display frame rate | 30 fps |
| Channels quantity | 8 channels |
| Product colour | Black |
| Video capturing speed | 30 fps |
| Certification | CE, FCC Class B, VCCI, C-Tick |
Ports & interfaces
| VGA (D-Sub) output ports | 1 |
| USB 2.0 ports quantity | 4 |
| eSATA ports quantity | 1 |
| RS-232 ports | 1 |
Networking
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN (RJ-45) ports | 2 |
Hard drive
| Hard drive size | 3.5 " |
| Number of hard drives supported | 2 |
| Maximum hard drive capacity | 6000 GB |
Processor
| Built-in processor | Dual-core Intel processor |
Memory
| Internal memory | 2 MB |
Optical drive
| Optical drive included |
Power
| Power consumption (max) | 31 W |
Weight & dimensions
| Dimensions (WxDxH) | 315 x 220 x 75 mm |
| Weight | 2270 g (5 lbs) |
Packaging content
| Handheld remote control |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 95 % |
