Gigabyte NVMe SSD M.2 512GB GP-GSM2NE3512GNTD

Out of stock
SKU
19_GP-GSM2NE3512GNTD_1
Special Price $66.86 Regular Price $90.00
MPN
GP-GSM2NE3512GNTD
UPC
889523019368

About this item
  • Form Factor: M.2 2280
  • Interface: PCI-Express 3.0 x4, NVMe 1.3
  • Total Capacity: 512GB*
  • Warranty: Limited 5-year or 800TBW
  • Sequential Read Speed : up to 1700 MB/s**
  • Sequential Write speed : up to 1550 MB/s**
  • HMB (Host Memory Buffer) supported
  • TRIM & S.M.A.R.T supported

The bold memory space and lightning fast speeds of the M.2 SSD provide a better user experience for your operating system and programs.

With Gigabyte NVMe SSD, your computer runs faster and can handle complex software applications with ease.

The limits of the physical size of hard drives are not a reason to give up.

Sequential read speeds up to 1700 MB/s. Sequential write speeds up to 1550 MB/s. GIGABYTE M.2 PCIe SSD gives you faster data transferring experience.


The GIGABYTE SSDs and the M.2 PCIe SSDs have the ability to break the limitations of the SATA interface, giving you an exceptional speed compared to traditional hard drives.

Host Memory Buffer (HMB)

HMB is a new feature in Windows 10 to allow computers with SSD to use some of the DRAM as a buffer for caching.

SSD Tool Box

The updated SSD Tool Box is an app that monitors SSD's health, provides general information, and also detects sensor temperature. Furthermore, users can erase data with the secure erase function.

GIGABYTE NVMe drives have a MTBF of 1.5 million hours and a 5-year warranty.

Specifications
Performance
Solid-state drive capacity 512 GB
Read speed 1700 MB/s
Write speed 1550 MB/s
NVM Express (NVMe) supported
NVM Express (NVMe) version 1.3
PCI Express interface data lanes x4
Random read (4KB) 27000 IOPS
Random write (4KB) 34000 IOPS
S.M.A.R.T. support
TRIM support
Component for PC/Notebook
TBW rating 800
Mean time between failures (MTBF) 1500000 h
Design
SSD form factor M.2
Power
Power consumption (read) 3.3 W
Power consumption (write) 2.8 W
Power consumption (idle) 0.0018 W
Features
Interface PCI Express 3.0
Operational conditions
Operating temperature (T-T) 0 - 70 °C
Storage temperature (T-T) -40 - 85 °C
Weight & dimensions
Width 80 mm (3.12 ")
Depth 22 mm (0.86 ")
Height 2.3 mm (0.09 ")
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for GP-GSM2NE3512GNTD by GIGABYTE you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
