Panorama Antennas LPAMM-BC3G-26-3SP network antenna Omni-directional antenna SMA 5 dBi
Free 30 Days Returns
MPN
LPAMM-BC3G-26-3SP
About this item
2G/3G/4G, Omni-directional, 2x 3m RG174 SMA Plug
The LP[G]AM-BC3G-26 range has been designed to provide MiMo Cellular / LTE antenna function for IoT and M2M applications.
The compact, robust low-profile housing is weatherproof and contains two antenna elements with effective isolation and correlation covering all current global cellular and LTE bands in freq. range 698-960/1710-3800MHz. The LG version includes an active GPS/GNSS/Galileo/Beidou antenna for applications which require position or timing function.
The antenna can be fitted on a non- conductive panel if required* and offers easy, quick, secure and weatherproof installation with the single hole mounting bush and acrylic adhesive sealing pad. Supplied with integrated 3m (10’) cables and SMA plug connectors, the antenna will offer plug and play connectivity with many different terminals.
The compact, robust low-profile housing is weatherproof and contains two antenna elements with effective isolation and correlation covering all current global cellular and LTE bands in freq. range 698-960/1710-3800MHz. The LG version includes an active GPS/GNSS/Galileo/Beidou antenna for applications which require position or timing function.
The antenna can be fitted on a non- conductive panel if required* and offers easy, quick, secure and weatherproof installation with the single hole mounting bush and acrylic adhesive sealing pad. Supplied with integrated 3m (10’) cables and SMA plug connectors, the antenna will offer plug and play connectivity with many different terminals.
Specifications
Performance
| Frequency band | 0.698-0.96/1.71-3.8 GHz |
| Impedance | 50 Ω |
| Antenna gain level (max) | 5 dBi |
Features
| Antenna type | Omni-directional antenna |
| Antenna connector type | SMA |
| Cable length | 3 m |
| Housing material | Acrylonitrile styrene acrylate (ASA) |
| Product colour | Black |
Power
| Power consumption (max) | 20 W |
Operational conditions
| Operating temperature (T-T) | -30 - 70 °C |
Weight & dimensions
| Width | 45 mm (1.76 ") |
| Depth | 150 mm (5.85 ") |
| Height | 61 mm (2.38 ") |
| Weight | 360 g (0.79 lbs) |
Other features
| 1 |
