Clone M.2 NVMe drives without a host computer, or access the drives when connected to a computer via USBThis M.2 NVMe drive duplicator with a USB 3.2 Gen2x2 (20Gbps) host port offers high-speed duplication capabilities of up to 90GB per minute, providing efficient and fast cloning of storage devices.High-Speed M.2 NVMe DuplicationClone or duplicate M.2 NVMe solid-state drives (SSDs) without the need for a computer. This device requires no drivers or software and offers high-performance sector-by-sector duplication rates of up to 90GBpm and works with any file format, copying the entire drive.NVMe Drive Access over USB 3.2 Gen2x2The USB 20Gbps host connection enables external access and storage functionality for M.2 NVMe drives, facilitating data transfer between different computers without the need for internal drive installation.Compact and User-FriendlyThe device has a small form factor, requiring minimal desktop or storage space. LEDs display progress, status, and power, while an audible buzzer confirms duplication completion. The device features active and passive cooling to ensure optimal performance.The top-loading (toaster-style) design accommodates all PCIe M.2 (M-Key) drives, including those with pre-installed heat sinks. The device supports 4Kn sector size. Please note that the target disk must be equal to or larger than the source disk.The StarTech Advantage
Specifications
Technical details
Product type
HDD/SSD duplicator
Number of simultaneous copies
1
copies
Interface
USB 3.2 Gen 2 (3.1 Gen 2)
Duplicator operating modes
Copy
USB connector type
USB Type-C
Product colour
Black
Housing material
Plastic
Transfer rate
20000
MB/s
Transfer rate
90
GB/min
Hot-swap drive bays
Plug and Play
Chipset
JMS586U
Number of fans
1
fan(s)
Sustainability compliance
Fan diameter
60
mm
Sustainability certificates
RoHS
LED indicators
Y
Hard drive
SSD support
Solid-state drive interface
M.2
Power
Power consumption (typical)
0.1
W
AC input voltage
100 - 240
V
Output voltage
12
V
Output current
2
A
Input current
0.6
A
Plug type
Type M
Included power plug types
ANZ, EU, NA, UK
Operational conditions
Operating relative humidity (H-H)
20 - 80
%
Storage temperature (T-T)
-20 - 55
°C
Operating temperature (T-T)
5 - 55
°C
Weight & dimensions
Dimensions (WxDxH)
77 x 77 x 44
mm
Weight
129
g
(0.28 lbs)
Packaging data
Package depth
90
mm
Package weight
140
g
Cables included
USB Type-A to USB Type-C, USB Type-C to USB Type-C
Package height
95
mm
AC adapter included
Package width
160
mm
Manual
Logistics data
Master carton length
338
mm
Master carton width
500
mm
Master carton height
220
mm
Quantity per master carton
20
pc(s)
Note:
