StarTech.com 1:1 M.2 NVMe Drive Duplicator, Standalone M.2 SSD Cloner/Copier up to 90GBpm, USB 3.2 20Gbps M.2 Dual-Bay Drive Dock, USB-C/A Cables Included

In stock
SKU
14_M2-HDD-DUPLICATOR-N1_1
$195.00
Eligible for Free Shipping & Free Returns
MPN
M2-HDD-DUPLICATOR-N1
UPC
065030898003
About this item
StarTech.com 1:1 M.2 NVMe Drive Duplicator, 90GBpm Standalone M.2 SSD Cloner/Copier, USB-C 3.2 20Gbps M.2 Dual-Bay Drive Dock
Clone M.2 NVMe drives without a host computer, or access the drives when connected to a computer via USBThis M.2 NVMe drive duplicator with a USB 3.2 Gen2x2 (20Gbps) host port offers high-speed duplication capabilities of up to 90GB per minute, providing efficient and fast cloning of storage devices.High-Speed M.2 NVMe DuplicationClone or duplicate M.2 NVMe solid-state drives (SSDs) without the need for a computer. This device requires no drivers or software and offers high-performance sector-by-sector duplication rates of up to 90GBpm and works with any file format, copying the entire drive.NVMe Drive Access over USB 3.2 Gen2x2The USB 20Gbps host connection enables external access and storage functionality for M.2 NVMe drives, facilitating data transfer between different computers without the need for internal drive installation.Compact and User-FriendlyThe device has a small form factor, requiring minimal desktop or storage space. LEDs display progress, status, and power, while an audible buzzer confirms duplication completion. The device features active and passive cooling to ensure optimal performance.The top-loading (toaster-style) design accommodates all PCIe M.2 (M-Key) drives, including those with pre-installed heat sinks. The device supports 4Kn sector size. Please note that the target disk must be equal to or larger than the source disk.The StarTech Advantage
Specifications
Technical details
Product type HDD/SSD duplicator
Number of simultaneous copies 1 copies
Interface USB 3.2 Gen 2 (3.1 Gen 2)
Duplicator operating modes Copy
USB connector type USB Type-C
Product colour Black
Housing material Plastic
Transfer rate 20000 MB/s
Transfer rate 90 GB/min
Hot-swap drive bays
Plug and Play
Chipset JMS586U
Number of fans 1 fan(s)
Sustainability compliance
Fan diameter 60 mm
Sustainability certificates RoHS
LED indicators Y
Hard drive
SSD support
Solid-state drive interface M.2
Power
Power consumption (typical) 0.1 W
AC input voltage 100 - 240 V
Output voltage 12 V
Output current 2 A
Input current 0.6 A
Plug type Type M
Included power plug types ANZ, EU, NA, UK
Operational conditions
Operating relative humidity (H-H) 20 - 80 %
Storage temperature (T-T) -20 - 55 °C
Operating temperature (T-T) 5 - 55 °C
Weight & dimensions
Dimensions (WxDxH) 77 x 77 x 44 mm
Weight 129 g (0.28 lbs)
Packaging data
Package depth 90 mm
Package weight 140 g
Cables included USB Type-A to USB Type-C, USB Type-C to USB Type-C
Package height 95 mm
AC adapter included
Package width 160 mm
Manual
Logistics data
Master carton length 338 mm
Master carton width 500 mm
Master carton height 220 mm
Quantity per master carton 20 pc(s)
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for M2-HDD-DUPLICATOR-N1 by StarTech.com you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
