StarTech.com 1ft CAT6a Ethernet Cable - Aqua - Low Smoke Zero Halogen (LSZH) - 10GbE 500MHz 100W PoE++ Snagless RJ-45 w/Strain Reliefs S/FTP Network Patch Cord

Out of stock
SKU
6_NLAQ-1F-CAT6A-PATCH_1
$22.00
MPN
NLAQ-1F-CAT6A-PATCH
UPC
065030896351

About this item
StarTech.com 1ft CAT6a Ethernet Cable - Low Smoke Zero Halogen (LSZH) - 10 Gigabit 500MHz 100W PoE RJ45 S/FTP Aqua Network Patch Cord Snagless w/Strain Relief (NLAQ-1F-CAT6A-PATCH)
LSZH | 10GbE | 100W PoE++ | Snagless RJ-45

Cat6a Ethernet Low-Smoke Zero-Halogen (LSZH) Shielded cables support Multi-Gigabit/Multi-speed 1/2.5/5Gbps/10Gbp connections. It offers robust protection against electromagnetic interference (EMI/RFI) and noise, ensuring a fast, safe, and reliable network.

Low-Smoke Zero-Halogen (LSZH) CAT6A Ethernet Cable

LSZH Cat6a Network Cables are more eco-friendly than PVC cables. In the event of a fire, LSZH cables produce low levels of corrosive fumes and smoke. Low levels of acrid combustion pollutants promote increased visibility, resulting in safe and quick building evacuations by staff and first responders.

100W Power over Ethernet (PoE++)

This high performance Ethernet cable complies with the IEEE 802.3bt-2018 standard. It supports 100W PoE++, providing ample power to Type 4 PoE devices.

RJ45 Connectors with Snagless Clips

The Cat6a cable features snag-less connectors. Snagless molded boots protect the tab/latch on each RJ45 connector. The boots prevent the cable from snagging during cable routing and/or installation into network devices.

The molded boots feature integrated strain reliefs that prevent sharp connector/cable angles at the termination points.

This product is backed for life, including free lifetime 24/5 multi-lingual technical assistance.

The StarTech Advantage
Specifications
Features
Product colour Aqua colour
Cable shielding S/FTP (S-STP)
Connector 1 RJ-45
Connector 2 RJ-45
Connector 1 form factor Straight
Connector 2 form factor Straight
Connector 1 gender Male connector
Connector 2 gender Male connector
Connector contacts plating Gold
Cable shape Round
Data transfer rate 10000 Mbit/s
Frequency 500 MHz
Cabling technology 10GBase-T
Ethernet interface type 2.5 Gigabit Ethernet,5 Gigabit Ethernet,10 Gigabit Ethernet, Gigabit Ethernet
AWG wire size 27
Power over Ethernet (PoE)
Plug and Play
Conductor material Copper
Conductor type Stranded
Power over Ethernet (PoE) type supported PoE++ (4PPoE)
Total Power over Ethernet (PoE) budget 100 W
Cable length 0.305 m
Cable standard Cat6a
Jacket material Low smoke zero halogen (LSZH)
Snagless cable boot
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -20 - 60 °C
Operating relative humidity (H-H) 0 - 85 %
Weight & dimensions
Outer diameter 5.7 mm
Weight 21 g (0.05 lbs)
Packaging data
Quantity per pack 1 pc(s)
Package width 220 mm
Package depth 195 mm
Package height 8 mm
Package weight 28.8 g
Logistics data
Master carton width 430 mm
Master carton length 220 mm
Master carton height 290 mm
Quantity per master carton 220 pc(s)
Other features
CE, RoHS
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for NLAQ-1F-CAT6A-PATCH by StarTech.com you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
