Thermaltake Smart W3 500W power supply unit 24-pin ATX ATX Black

SKU

19_PS-SPW-0500NNFAWU-1_1

Be the first to review this product

$45.00

Visit our Thermaltake Store

MPN

PS-SPW-0500NNFAWU-1

UPC

841163094464

Recommended Product

Thermaltake Smart 600W ATX power supply unit

$52.00

About this item

500 W, APFC, 24 Pin, ATX 12V, 2x PCI-E, 4x SATA, 4x Peripheral, 120 mm FDB, 10-5A, 50/60Hz, 100-240V, 150 x 86 x 140 mm

Description
Specifications

Power up with Efficiency and Stability

The Smart W3 series is certified by 80 PLUS efficiency and designed to meet ATX 3.1 standards, offering 500W, 600W, and 700W options. It's perfect for budget-conscious users seeking an efficient and reliable entry-level power supply, backed by a solid 5-year warranty.

ATX 3.1 Ready

Smart W3 series is fully compatible with ATX 3.1 specifications which supports up to 200% power excursion, reaches 60% low load efficiency and complies with required power supply timing standards.

Silent Cooling

Ultra-quiet 120mm cooling fan delivers excellent airflow at an exceptionally low noise level.

High Quality 105°C/221°F Main Capacitor

High quality main capacitor greatly improves the power supplies durability and ensures the Smart W3 series is stable and reliable.

High Amperage Single +12V Rail & DC to DC Design

Powerful single +12V rail can properly deliver the power you need for the best compatibility. The use of DC to DC circuit design provides very stable operation and enhanced voltage regulation.

Built-in Industrial Grade Protection

To protect the hardware, Smart W3 is built with industry grade protections: OCP(Over Current Protection), OVP (Over Voltage Protection), UVP(Under Voltage Protection), OPP(Over Power Protection), SCP(Short Circuit Protection), OTP(Over Temperature Protection).

Non-Modular Soft Cable Design

Smart W3 series comes with soft black cables, designed to make cable installation an easy task while fully powering the system at optimal voltages.

Specifications

Power

Total power	500 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	10 - 5 A
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	100 W
Combined power (+12V)	500 W
Combined power (+5V)	100 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	16 A
Max output current (+12V)	41.67 A
Max output current (+5V)	16 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	3 A
Power Good signal delay range	100 - 150 ms
Power protection features	Over current, Over power, Over voltage, Short circuit, Under voltage
Hold time	17 ms

Cooling

Fan diameter	120 mm
Cooling type	Active
Number of fans	1 fan(s)

Ports & interfaces

Motherboard power connector	24-pin ATX
Number of SATA power connectors	4
Peripheral (Molex) power connectors (4-pin)	4
PCI Express power connectors (6+2 pin)	2
CPU power connector (4+4 pin)
Cabling type	Non-Modular

Performance

Purpose	PC
Power supply unit (PSU) form factor	ATX
ATX version	3.1
Bearing technology	FDB
On/off switch
Mean time between failures (MTBF)	100000 h

Design

Product colour

Black

Operational conditions

Operating temperature (T-T)	5 - 40 °C
Storage temperature (T-T)	-40 - 55 °C
Operating relative humidity (H-H)	20 - 85 %
Storage relative humidity (H-H)	10 - 95 %

Weight & dimensions

Width	150 mm (5.85 ")
Depth	140 mm (5.46 ")
Height	86 mm (3.35 ")

Certificates

80 PLUS certification

80 PLUS

Other features

	CB, Federal Communications Commission (FCC), ICES, cTUVus
	Y
