Intel Xeon E-2468 processor 2.6 GHz 24 MB
Eligible for Free Shipping & Free Returns
MPN
CM8071505024706
About this item
Intel® Xeon® E-2468 Processor (24M Cache, 2.60 GHz) FC-LGA16A, Tray
Intel® Xeon® E-2468 Processor (24M Cache, 2.60 GHz) FC-LGA16A, Tray
Specifications
Processor
| Processor manufacturer | Intel |
| Processor base frequency | 2.6 GHz |
| Processor family | Intel Xeon E |
| Processor cores | 8 |
| Processor socket | LGA 1700 |
| Processor model | E-2468 |
| Processor threads | 16 |
| System bus rate | 16 GT/s |
| Performance cores | 8 |
| Processor operating modes | 64-bit |
| Processor cache | 24 MB |
| Box | |
| Processor boost frequency | 5.2 GHz |
| Processor codename | Raptor Lake |
| Stepping | B0 |
| Maximum number of DMI lanes | 8 |
| Processor ARK ID | 236184 |
Memory
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory channels | Dual-channel |
| ECC |
Graphics
| On-board graphics adapter | |
| Discrete graphics adapter | |
| On-board graphics adapter model | Not available |
| Discrete graphics adapter model | Not available |
Power
| Thermal Design Power (TDP) | 65 W |
Features
| Execute Disable Bit | |
| Idle States | |
| Thermal Monitoring Technologies | |
| Use conditions | Server/Enterprise |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 5.0 |
| PCI Express configurations | 2x8+1x4,1x16+1x4 |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| Embedded options available | |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Market segment | Server |
| Harmonized System (HS) code | 8542310001 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
Processor special features
| Intel® Hyper Threading Technology (Intel® HT Technology) | |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Trusted Execution Technology | |
| Intel® AES New Instructions (Intel® AES-NI) | |
| Enhanced Intel SpeedStep Technology | |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.2 GHz |
| Intel® Turbo Boost Technology 2.0 frequency | 5.2 GHz |
| Intel® Transactional Synchronization Extensions | |
| Intel® Total Memory Encryption | |
| Intel Turbo Boost Max Technology 3.0 | |
| Intel 64 | |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) | |
| Intel Virtualization Technology (VT-x) | |
| Intel® Secure Key | |
| Microprocessor PCIe Revision | Gen 5 |
| Intel Virtualization Technology for Directed I/O (VT-d) | |
| Mode-based Execute Control (MBE) | Y |
| Intel® OS Guard | |
| Intel VT-x with Extended Page Tables (EPT) | |
| Intel® Optane™ DC Persistent Memory Supported | |
| Intel® Boot Guard | |
| Intel® Total Memory Encryption - Multi Key |
Operational conditions
| Tjunction | 100 °C |
Technical details
| Status | Launched |
| Launch date | Q4'23 |
| Servicing status | Baseline Servicing |
Other features
| Maximum internal memory | 128 GB |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
CM8071505024706 by Intel
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
