Manhattan USB-A Contact Smart Card Reader, 12 Mbps, Friction type compatible, External, Windows or Mac, Cable 105cm, Three Year Warranty, Blister

MPN
102049
UPC
766623102049

About this item
Contact Smart Card Reader, USB, Friction type compatible, External, Windows or Mac, Cable 105cm, Black, Blister
Improve secured data and access protection.
Smart card technology finds popular applications in security and access control, financial transactions, medical records, loyalty programs, toll and vending collection, enterprise or single-user network sign-on and more that require secure information exchanges. Contact smart cards have a contact, or chip area with several contact pads that, when inserted into a Manhattan Smart Card Reader, can authenticate the user and safely transfer information between the card and the host computer. Smart cards are utilized extensively in Europe and Asia, and the use of smart cards is growing in North and South America. They replace less secure and less reliable barcode ID and magnetic stripe cards to provide flexible and standard transactions and strong, tamper-resistant authentication with minimal human intervention.

Quick and Easy Installation
Ideal for desktop and notebook computers without built-in readers, the Manhattan Smart Card Reader is easily installed using any USB port and the included software and driver CD. Plug and play with Windows and Mac compatibility, it requires no external power supply or cables
- just a simple USB connection.
Specifications
Features
Placement supported Indoor
Product colour Black
Mean cycles between failures (MCBF) 200000
Housing material Acrylonitrile butadiene styrene (ABS)
Plug and Play
LED indicators Activity, Power
Cable length 1.05 m
Compliance industry standards 2-line, 3-line, SLE4418, 4428, 4432, 4442, AT88SC1608, 45D041, I2C
Ports & interfaces
Interface USB 2.0
Power
USB powered
Operating voltage 5 V
System requirements
Windows operating systems supported Windows 10, Windows 7, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Mac compatibility
Linux operating systems supported Y
Mac operating systems supported Y
Certificates
Certification FCC, CE, RoHS2, CCID, EMV
Weight & dimensions
Width 65 mm (2.54 ")
Height 15 mm (0.59 ")
Depth 85 mm (3.32 ")
Weight 60 g (0.13 lbs)
Packaging content
Quick installation guide
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -35 - 70 °C
Other features
RoHS
USB
