VIVOTEK ND9542P network video recorder
Eligible for Free Shipping & Free Returns
MPN
ND9542P
VIVOTEK ND9542P network video recorder
Specifications
Performance
| Video input channels | 32 channels |
| Alarm input channels | 16 |
| Alarm output channels | 8 |
| Supported resolutions | 3840x2160, 1920x1080 |
| Maximum resolution | 7680 x 2560 pixels |
| Video motion detection | |
| Audio formats supported | G.711, G.726 |
| Video formats supported | H.264, H.265 |
| Image formats supported | JPEG |
| Operating system installed | Embedded Linux |
| PTZ control (Pan/Tilt/Zoom) | |
| PTZ modes | Preset point |
Wireless LAN features
| Wi-Fi |
Storage
| RAID support |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 2 |
| Power over Ethernet (PoE) | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| RAID levels | 0,1,5 |
| HDMI output | |
| HDMI ports quantity | 1 |
| VGA (D-Sub) output ports | 1 |
| USB 2.0 ports quantity | 2 |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 1 |
| Audio output | 1 |
| RS-485 ports | 1 |
| Supported network protocols | IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS |
Power
| Power consumption (max) | 300 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Operational conditions
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
Weight & dimensions
| Width | 432 mm (16.85 ") |
| Depth | 421 mm (16.42 ") |
| Height | 66 mm (2.57 ") |
| Weight | 4600 g (10.14 lbs) |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
ND9542P by VIVOTEK
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
