Supermicro AOC-SHG3-4M2P-O Add-On Card with 4x M.2 sockets for NVMe

An AOC-SHG3-4M2P is an M.2 SSD carrier card that supports four NVMe Non-Volatile Memory Express (NVME) solid state drives (SSDs).

Supermicro's AOC-SHG3-4M2P M.2 NVMe SSD carrier provides four internal sockets for four different lengths of M.2 SSD along with a dedicated on-board switch that allows dense storage with efficient performance.

Supermicro NVMe Card has been designed to fit a standard PCI-E 3.0 x8 slot and requires minimal BIOS or OS modification to work immediately.

Various ranges of solutions; from entry-level SMB systems to enterprise class server platforms, can take advantage of this powerful add-on card for increased performance and scalability.

SSDs with NVMe technology outperform SAS/SATA SSDs in embedded/IPC and desktop/gaming station solutions.

Using PCI Express technology, M.2 solid-state storage is a high-performance, scalable solution, easily streamlined for enterprise and client applications.

The Supermicro AOC-SHG3-4M2P is designed with movable standoffs which support three different M.2 SSD lengths and permanent standoffs which support one M.2 SSD length.

M.2 Length:

• 22 mm x 42 mm Standoff Positions 1: SRW1, SRW5, SRW9, and SRW13;
• 22 mm x 60 mm Standoff Positions 2: SRW2, SRW6, SRW10, and SRW14;
• 22 mm x 80 mm Standoff Positions 3: SRW3, SRW7, SRW11, and SRW15;
• 22 mm x 110 mm Standoff Positions 4: SRW4, SRW8, SRW12, and SRW16;
