ASUS Lyra IEEE 802.11ac Home Mesh Ethernet Wireless Router

MPN
90IG04N0-MM3G20
UPC
192876039977

About this item

IEEE 802.11a/b/g/n/ac, 1 x RJ45 WAN, 1 x RJ45 LAN, 256 MB Flash, 512 MB RAM, MU-MIMO, Bluetooth, 2 x 8 W RMS, 975 g

All-In-One Smart Voice Router

AC2200 Tri-Band Mesh WiFi Router with Bluetooth Speaker with AiMesh and Amazon Alexa Built-in, Trend Micro AiProtection Pro Network Security, Two 8W Stereo Speakers

Lyra Voice is a ground-breaking three-in-one mesh WiFi router that includes Amazon Alexa and powerful audio speakers.

Connect all of your smart devices around your home with robust Tri-band, AC2200-class Wi-Fi and secure your privacy with Trend Micro's AiProtection Pro.

By simply speaking to Lyra Voice, you may get help from Alexa and enjoy music with outstanding sound quality. Everything you need to live smartly is right here. You only need to 'ask.'

WiFi Extending Your Voice Has Been Heard.

Lyra Voice works flawlessly with practically all WiFi routers on the market to boost your home's existing WiFi signal.

Lyra Voice can be installed anyplace you need stronger WiFi and a helpful smart assistant.

Stream music wherever you go, whether you're cooking dinner or relaxing with friends on the patio.

Improved Internet Security for Your Family and Devices

Lyra Voice incorporates AiProtection Pro powered by Trend MicroTM, which protects your devices and personal data from internet dangers by automatically updating security signatures on a regular basis. This comprehensive parental control system includes the ability to restrict specific websites and mobile app kinds.

The Way You Want by Lyra Voice

Lyra Voice can be used in three ways: as a standalone router, as part of an AiMesh whole-home WiFi system, or as a wifi extender for any router you already possess.

WiFi Mesh Blanket Throughout Your Home

Lyra Voice includes ASUS AiMesh technology, which allows you to integrate all AiMesh-compatible routers into a single WiFi system and enjoy a consistent WiFi signal across your home.

To give the finest WiFi experience, AiMesh routers 'speak' to each other, monitor the signal quality to all connected devices, and smoothly exchange device connections among them as needed.

All of the strong networking functionalities available on the principal router can be used throughout the system.

All-In-One Device Hub

You may use ASUS Lyra Voice to keep all smart devices connected to WiFi and control over 20,000 devices globally using Alexa Skills.

Lyra Voice features three WiFi frequency bands, which means it has more ability to accommodate all of your WiFi devices.

Furthermore, the MU-MIMO technology allows Lyra Voice to transfer data with two compatible devices at the same time, eliminating the need for them to wait for each other.

Because of these WiFi designs, Lyra Voice is an excellent choice as the hub for your smart devices.

Stereo Speakers for Immersive Surround Sound

Lyra Voice has two stereo speakers inside, as well as passive radiators and bass reflex ports to increase low frequency sound resonance.

Lyra Voice can give immersive sound performance because to its sophisticatedly built speaker design and DTS surround sound technology, which enhances the spaciousness of the sound.

Bass Music Ultra-Wide Extender

On the left and right speakers, Lyra Voice features two passive radiators with concentric circle marks and hair-line surface treatment.

When playing low-frequency music, this design can aid to increase the width and strength of the bass extension.

Your voice was clearly heard.

Lyra Speech can hear your voice from any direction, even while playing music, thanks to far-field voice recognition technology and noise reduction.

When you say 'Alexa,' the LED on the front panel of the Lyra Voice turns blue, indicating that it is ready for your voice command.

Control

Although Alexa listens to you from a distance, you can still use the physical buttons on Lyra Voice to do basic functions.
For privacy, wake Alexa up, increase the volume, or deactivate the microphone.

Make the Internet a more secure environment for everyone.

Every member of your family, young or old, is exposed to the risks of the internet every time they go online.

Lyra Voice features AiProtection Pro with Advanced Parental Controls to give you complete peace of mind, with commercial grade security for your home network and comprehensive, easy control of each family member's and device's online experience, all via the mobile app.

There is no subscription fee.

While some routers only provide three years of protection, ASUS AiProtection covers you for the life of your gear.

Defending Against Attacks

All common internet-based threats are blocked by an intrusion prevention system (IPS).

Restriction of Access to Malicious Websites

Trend Micro's official database is used by AiProtection to identify and block known dangerous sites, avoiding infection even before you click.

Detection and prevention of infections

Even if a device that is already infected is connected to Lyra Voice, AiProtection protects any personal data on the device from being compromised.

Superior Parental Controls

Keep your children safe when they use the internet.

AiProtection's cutting-edge parental controls consolidate all of the management capabilities you want in a single location, and the user-friendly interface makes it simple to examine and apply security settings to all devices owned by individual family members.

Specifications
WAN connection
Ethernet WAN
DSL WAN
SIM card slot
3G/4G USB modem compatibility
WAN connection type RJ-45
Wireless LAN features
Wi-Fi band Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Top Wi-Fi standard Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max) 867 Mbit/s
Wi-Fi standards 802.11a,802.11b,802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band) 400 Mbit/s
WLAN data transfer rate (second band) 867 Mbit/s
WLAN data transfer rate (third band) 867 Mbit/s
Ethernet LAN features
Ethernet LAN
Ethernet LAN interface type Gigabit Ethernet
Ethernet LAN data rates 10,100,1000 Mbit/s
Cabling technology 10/100/1000Base-T(X)
Ports & interfaces
USB port
Ethernet LAN (RJ-45) ports 2
DC-in jack
Mobile networking
3G
4G
Networking
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11d, IEEE 802.11g, IEEE 802.11n
Antenna
Antenna type Internal
Antennas quantity 7
Management features
Web-based management
Security
Security algorithms WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Filtering
IP address filtering
MAC address filtering
Design
Product colour Black
Product type Portable router
On/off switch
Performance
Memory card slot(s)
Power
AC input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Output voltage 19 V
Output current 2.37 A
Power source type DC
Weight & dimensions
Height 75 mm (2.93 ")
Weight 975 g (2.15 lbs)
Width 270 mm (10.53 ")
Depth 75 mm (2.93 ")
Packaging content
Number of products included 1 pc(s)
AC adapter included
Manual
Software
Windows operating systems supported Windows 10, Windows 10 x64, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows ME, Windows Vista, Windows XP
Mac compatibility
Mac operating systems supported Mac OS X 10.1 Puma, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Other features
Internal memory 512 MB
Flash memory 256 MB
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for 90IG04N0-MM3G20 by ASUS you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
