ASUS ROG Rapture GT-AX11000 Pro wireless router Gigabit Ethernet Tri-band (2.4 GHz / 5 GHz / 5 GHz)

MPN
90IG0720-MU2A00
UPC
195553264341

About this item
2.4G Hz, 5 GHz-1, 5 GHz-2, USB 3.1, 4 x RJ45, Flash 256 MB, RAM 1 GB, 1.8 GHz
GT-AX11000 Pro Tri-Band WiFi 6 gaming router, 2.5G port, 10G port, enhanced hardware, ASUS RangeBoost Plus, 5.9 GHz, Triple-level game acceleration, free network security and AiMesh support

- High-efficiency WiFi 6 – Ultrafast WiFi 6 tri-band boosts speeds up to 11,000 Mbps, with 160 MHz channels for better efficiency and throughput
- Expanded coverage – Exclusive ASUS RangeBoost Plus improves signal range and overall coverage
- Flexible networking ports – One 2.5G port and one 10G port can be configured for either WAN or LAN operation
- Extreme quad-core CPU power – High-performance WiFi chipsets and 64-bit 2.0 GHz quad-core CPU take wireless signal processing to the next level
- Triple-level game acceleration – Online gaming gets network prioritization every step of the way, from PC to game server
- Expanded UNII4 spectrum – Additional high-power 160 MHz channel in 5 GHz increases backhaul capacity of the Mesh network

Primed and ready for battle

The ROG Rapture GT-AX11000 Pro is designed for gamers who want to keep multiple devices connected and still get incredible gaming performance. Enjoy up to eight simultaneous WiFi 6 streams for more video streaming, gaming and browsing for everyone in your home.

Expanded Coverage with RangeBoost Plus

RangeBoost Plus is the latest, most powerful evolution of the renowned and exclusive ASUS collection of wireless network technologies. It includes the next-gen Broadcom WiFi chipset and CPU plus multiple cutting-edge ASUS features to expand signal range and overall coverage by up to 38%*.

Whole-Home coverage

WiFi 6 uses OFDMA technology to deliver increased WiFi signal range and better coverage by dividing each wireless channel into smaller sub-channels. With ASUS AiMesh, you can use a single SSID for your entire home network, with seamless coverage and no more dead zones! It provides you superfast, reliable and secure WiFi connections, you’ll still get fast connection speed at the far end inside or outside your home.

Expanded UNII4 Spectrum

The GT-AX11000 Pro has been upgraded to support an expanded UNII4 spectrum featuring a high-powered 160MHz channel on the 5GHz band. This increases the backhaul capacity of the mesh and improves signal efficiency for roaming and coverage.
Specifications
WAN connection
Ethernet WAN
DSL WAN
SIM card slot
3G/4G USB modem compatibility
WAN connection type RJ-45
Wireless LAN features
Wi-Fi band Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Top Wi-Fi standard Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max) 4804 Mbit/s
Wi-Fi standards 802.11a,802.11b,802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
WLAN data transfer rate (first band) 4804 Mbit/s
WLAN data transfer rate (second band) 1148 Mbit/s
WLAN data transfer rate (third band) 4804 Mbit/s
Ethernet LAN features
Ethernet LAN
Ethernet LAN interface type Gigabit Ethernet
Ports & interfaces
USB port
DC-in jack
USB 3.0 (3.1 Gen 1) Type-A ports quantity 2
Ethernet LAN (RJ-45) ports 5
Networking
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Dynamic DNS (DDNS)
VPN Passthrough
Port forwarding
Protocols
DHCP server
DMZ support
DHCP client
Antenna
Antennas quantity 8
Management features
Reset button
WPS push button
Quality of Service (QoS) support
Universal Plug and Play (UPnP)
Security
Security algorithms 64-bit WEP,128-bit WEP, WPA-Enterprise, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPS
Access Control List (ACL)
System event log
URL filtering
Design
Product colour Black
Indication light
On/off switch
Product type Tabletop router
LED indicators LAN, Power, USB, WAN, WLAN, WPS
Performance
Built-in processor
Processor frequency 1.8 MHz
Processor cores 4
Power
Power source type DC
AC input voltage 110 - 240 V
AC input frequency 50/60 Hz
Output voltage 19 V
Output current 3.42 A
Weight & dimensions
Package depth 396 mm
Width 354.9 mm (13.84 ")
Package height 141 mm
Depth 354.9 mm (13.84 ")
Package weight 3720 g
Height 193.2 mm (7.53 ")
Weight 2180 g (4.81 lbs)
Package width 401 mm
Packaging content
Package type Box
Software
Windows operating systems supported Windows 11
Mac operating systems supported Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Other features
Internal memory 1000 MB
Flash memory 256 MB
3
Y
Y
Y
External
Y
3
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for 90IG0720-MU2A00 by ASUS you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
