EVGA Supernova 1300 G+ 80+ Gold 1300w Fully Modular

Out of stock
SKU
19_220-GP-1300-X1_1
Special Price $298.01 Regular Price $358.00
MPN
220-GP-1300-X1
UPC
843368052522

About this item

1300 W, Fully Modular, 80 PLUS Gold, 135 mm fan, FDB, DC-DC Converter

For businesses facing the challenge of keeping up with demand, EVGA is here to provide their customers with 1300 watts of power at low temperatures.

With built-in Quiet Fan technology, the power supply provides stable power output at any given time.

The SuperNOVA G+ PSU

line from EVGA features the new and improved SuperNOVA G+, with 80+ Gold efficiency.

With Supernova 1300 G+ 80+ Gold 1300w Fully Modular PSU, EVGA continues its tradition of quality and performance that began with the award-winning 1600 and 1300 G2.

Also on all models, there is a module for Variable Resistor (to increase voltage stability) and two modules for DC to DC for more efficient power switching, as well as EVGA's worldwide 10-year warranty on G+ power supplies.

When building a system, even the tiniest differences can make the difference between success or failure. With the 1300G+ power supplies, you can save space while maintaining quality, as they are 20mm shorter than their G2 counterparts.

The 1300 G+ 135mm Fluid Dynamic Bearing Fan is quiet and durable.

Due to their durability and low noise levels, double ball bearings are industry standard when power supplies are expected to handle heavy loads regularly. Fan bearings with Fluid Dynamic Bearings last longer, are quieter, and have reduced wear and tear.

A single 12v rail is included on the SuperNOVA G+. All SuperNOVA G+ power supplies feature 100% Japanese capacitors, a VR module, and a DC to DC converter. IEC 62368* compliant, this device produces a 96% efficiency rating, 0.60% to 0.61% at 12v.

Stable power to all connected devices, and load regulation.

In comparison to the G2 power supply line-up, the G+ power supply line-up reduces noise by up to 35% by using quiet, long-lasting fan bearings and an optimized fan curve.

Specifications
Power
Total power 1300 W
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Input current 8 - 15 A
Combined power (+3.3V) 120 W
Combined power (+12V) 1299.6 W
Combined power (+5V) 120 W
Combined power (-12V) 6 W
Combined power (+5Vsb) 15 W
Max output current (+3.3V) 24 A
Max output current (+12V) 108.3 A
Max output current (+5V) 24 A
Max output current (-12V) 0.5 A
Max output current (+5Vsb) 3 A
Efficiency 90 %
Power protection features Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Cooling
Fan diameter 135 mm
Number of fans 1 fan(s)
Fan location Top
Ports & interfaces
Motherboard power connector 24-pin ATX
Motherboard power cable length 600 mm
Number of SATA power connectors 12
SATA power cable length 550,650,750 mm
Peripheral (Molex) power connectors (4-pin) 6
Peripheral (Molex) power cable length 550,650,750 mm
EPS power connector (4+4 pin)
PCI Express power connectors (6+2 pin) 8
PCI Express power cable length 900 mm
CPU power connector (4+4 pin)
CPU power cable length 750 mm
ATX Power connector (24-pin)
Floppy drive power connector 1
Cabling type Modular
Performance
Purpose PC
Bearing technology FDB
On/off switch
Mean time between failures (MTBF) 100000 h
Design
Product colour Black
Operational conditions
Operating temperature (T-T) 0 - 50 °C
Weight & dimensions
Width 150 mm (5.85 ")
Depth 200 mm (7.8 ")
Height 86 mm (3.35 ")
Weight 3629 g (8 lbs)
Certificates
80 PLUS certification 80 PLUS Gold
Packaging data
Package type Box
Packaging content
Cables included AC, CPU, PCIe, Peripheral (Molex), SATA
Other features
CE, RoHS
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for 220-GP-1300-X1 by EVGA you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
