Honeywell PM43 label printer Thermal transfer 203 x 203 DPI Wired

Out of stock
SKU
26_PM43A11000040201_1
$2,940.72
MPN
PM43A11000040201
UPC
0783555016244

About this item
PM43, Color Touch interface, Thermal transfer 203DPI, 128MB Flash memory, 128MB SDRAM, Ethernet 10/100 Mbps, , Rewinder, Label Taken Sensor, Hanger
Programmable PM series smart printers offer you reliable performance for uptime assurance, quick deployment and integration, and the fastest throughput in their class – no PC required. The PM43/43c (101.6 mm/4 in) printers and the PM23c (50.8 mm/2 in) model are available in a variety of enclosure sizes and door types to fit your exact application.


Ready


Fast to deploy and easy to integrate, PM series printers fit into virtually any environment.


Reliable


Now on their third generation, the PM43, PM43c, and PM23c printers are members of the well-proven family of PM series mid-range industrial printers.


Fast


Rapid 304 mm/s (12 ips) print speed and consistent barcode printing quality with pin-point accuracy.


Smart


Run apps right inside the printer, control peripherals, and eliminate the need for a connected PC, using either C# for Printers or Fingerprint.


Connected


Flexible conectivity options, plus every PM series printer features a multilingual web interface for simple remote device management.


Vibrant


Avaiable with a large, color, multilingual, tamper-proof touchscreen or intuitive icon user interface.


Flexible


Available with three different enclosure sizes, all with multiple door configurations, to fit your needs plus a wide range of accessories for maximum media compatibility.


RFID Capable


Available in RFID-enabled configurations capable of simultaneously encoding and printing frequency-agile RFID tags.

The PM43/PM43c (101.6 mm/4 in) and PM23c (50.8 mm/2 in) Mid-Range Industrial Printers deliver proven reliability, fast drop-in deployment and integration, and advanced connectivity to maximize your uptime. They're ideal for applications in distribution centers, warehouses, manufacturing operations, and transportation centers.

The PM series was designed for easy integration and fast deployment.

Minimize workforce training and device support needs with intuitive features like a vibrant color touchscreen or intuitive icon user interface. Notifications are displayed right on screen, and the interface can be locked down to eliminate tampering.

And with the broadest connectivity options in their class – including Wi-Fi and Cisco CCX certifications, plus additional Bluetooth® connectivity – PM series quickly interface with virtually any IPv4 or IPv6 network.

PM printers offer outstanding performance in harsh environments thanks to a rugged metal enclosure and the top print speed in their class at 304 mm/s (12 ips). Beyond the productivity of speed, PM printers also enable you to work smarter by reducing labeling errors and increasing process efficiency.

Plus, in-printer apps can directly control other devices such as scanners, scales, keyboard and other peripherals – without the need for an attached computer.
Specifications
Printing
Print technology Thermal transfer
Maximum resolution 203 x 203 DPI
Print speed 300 mm/sec
Standard printer languages DPL, IPL, XML, ZPL II
Maximum printing width 108 mm
Display
Display LCD
Touchscreen
Colour display
Ports & interfaces
RS-232 ports 1
Connectivity technology Wired
Ethernet LAN
USB 2.0 ports quantity 1
Memory
Flash memory 128 MB
Internal memory 128 MB
Paper handling
Maximum label width 114 mm
Maximum roll diameter 80 mm
Maximum label length 4.8 m
Performance
Built-in barcodes 1D,2D, EAN128, POSTNET
Built-in RFID module
RFID frequency range 865 - 928 MHz
Image formats supported BMP, GIF, PCX, PNG
Design
Product colour Black, Grey
Power
AC input voltage 100 - 240 V
AC input frequency 45 - 65 Hz
Power consumption (standby) 9 W
Technical details
PC connection RS-232/USB
Weight & dimensions
Width 284 mm (11.08 ")
Depth 483 mm (18.84 ")
Height 295 mm (11.51 ")
Weight 15820 g (34.88 lbs)
System requirements
Windows operating systems supported Y
Operational conditions
Operating relative humidity (H-H) 20 - 80 %
Storage temperature (T-T) 20 - 70 °C
Operating temperature (T-T) 5 - 40 °C
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for PM43A11000040201 by Honeywell you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
