Intel X710-DA4 Internal Fiber 10000Mbit/s

Out of stock
SKU
795530
Special Price $445.98 Regular Price $585.00
MPN
X710DA4FH#2
UPC
735858281836

About this item
Ethernet Converged Network Adapter X710-DA4
Intel® Ethernet Power Management Technology provides solutions to common power management approaches by reducing idle power, reducing capacity and power as a function of demand, operating at maximum energy efficiency whenever possible, and enabling functionality only when needed.
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance
Specifications
Ports & interfaces
Connectivity technology Wired
Internal
Host interface PCI-E
Interface Fiber
Fiber ports quantity 4
Fiber optic connector SFP+
Bandwidth
Data transfer rate (max) 10000 Mbit/s
Networking
Chipset XL710-AM1
Ethernet LAN
Ethernet LAN data rates 10000 Mbit/s
Networking standards IEEE 802.1as, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ad
VLAN tagging
LAN controller Intel(R) XL710
Fiber ethernet cabling technology 10GBASE-LR,10GBASE-SR
Flow control support
Power
Power consumption (typical) 6.9 W
Protocols
Supported network protocols TCP, UDP, IP
Management protocols PXE, SNMP, RMON
Design
Product colour Black, Green
PCI Card form factor Full-height
LED indicators Y
Product family Intel 10 Gigabit server adapter
Product series Intel Converged X710
Product codename Fortville
Performance
iWARP/RDMA
Fiber Channel over Ethernet
Intel Ethernet Power Management
Intel Data Direct I/O Technology
Storage-over-ethernet
On-chip QoS and Traffic Management
Speed & slot width 8.0 GT/s, x 8 Lane
Ethernet adapter ARK ID 83965
Intel Flexible Port Partitioning
Intel Virtual Machine Device Queues (VMDq)
Number of VLANs 4096
Intelligent Offloads
PCI-SIG* SR-IOV Capable
Intel® Virtualization Technology (Intel® VT) VT-c
System requirements
Linux operating systems supported RedHat EL Linux 6.0
Other operating systems supported FreeBSD
Server operating systems supported Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Weight & dimensions
Width 111.05 mm (4.33 ")
Depth 167.08 mm (6.52 ")
Certificates
Certification FCC B, UL, CE, VCCI, BSMI, CTICK, KCC
Operational conditions
Operating temperature (T-T) 0 - 55 °C
Storage temperature (T-T) -40 - 70 °C
Storage relative humidity (H-H) 35 - 90 %
Other features
Cable type SFP+ Direct Attached Twin Axial Cabling up to 10m
Intel Trusted Execution Technology
Embedded options available
Compatible operating systems intel.com/support/EthernetOS
Message signal interrupt
Intel Virtualization Technology for Connectivity (VT-c)
Interface type PCIe v3.0 (8.0 GT/s)
Low halogen options available
Storage Over Ethernet iSCSI NFS
Technical details
Status Launched
Number of QPI links Quad
Network interface card type Server
Product name Intel Ethernet Converged Network Adapter X710-DA4
Product brief URL http://www.intel.com/content/www/us/en/network-adapters/converged-network-adapters/ethernet-x710-brief.html
Product type 13
Halogen free
Born on date Q4'14
Launch date 2014-10-01T00:00:00
Bracket height Full Height
Market segment SRV
Network interface card cable medium Copper
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for X710DA4FH#2 by Intel you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
