Aten CE610A Transmitter & Receiver KVM extender

SKU

14_CE610A_1

Be the first to review this product

$803.00

Visit our Aten Store

MPN

CE610A

UPC

672792007163

CE610A

The CE610A USB DVI KVM Extender is a DVI and USB Extender that supports ExtremeUSB ® and HDBaseT technology. The CE610A can extend DVI and USB 2.0 signals up to 300 ft (100 m) from the source using a single Cat 5e/6 cable. The CE610A is equipped with USB connectors which allow you to extend any USB device between the units. The USB functionality provides not only peripheral sharing but also the support for touch panel control and fi le transfer. The CE610A is ideal for situations where touch panel is required, such as transportation centers, medical facilities, shopping malls, industrial kiosks, and when synchronizing for files / folders between portable and desktop computers are required

Specifications

Features

Type	Transmitter & Receiver
Connectivity technology	Wired
Maximum digital resolution	1920 x 1200 pixels
Firmware upgradeable
Material	Metal
USB 2.0 ports quantity	3
USB data transfer rates	40 Mbit/s
LED indicators	Link, Power, USB, Video

Transmitter

RJ-45 ports quantity (transmitter)

Power

Power consumption (transmitter) (max)

15 W

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80 %

Weight & dimensions

Transmitter width	117.9 mm
Transmitter depth	182 mm
Transmitter height	28.7 mm
Transmitter weight	620 g
Receiver width	117.9 mm
Receiver depth	182 mm
Receiver height	28.7 mm
Receiver weight	620 g

Packaging content

AC adapter included
Cables included	DVI, USB
Manual
Mounting bracket(s) included

Technical details

Video in

DVI-D

Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for CE610A by Aten you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
