NZXT N7 Z490 ATX LGA1200 Motherboard
SKU
19_N7-Z49XT-W1_1
Special Price
$221.62
Regular Price
$275.00
About this item
- LGA socket 1200 Intel Z490;
- 4 x DD4 DIMM;
- Intel HD Graphics;
- 2.5 Gigabit LAN, Wi-Fi 6 + Bluetooth 5.1;
- 8 Ch HD Audio;
- 4 x SATA 6Gb/s, 2 x M.2, 1 x USB 3.2 Gen 2 (Light Blue), 2 x USB 3.2 Gen 1 (Blue), 1 x USB 3.2 Gen 2 Type-C, 2 x USB 2.0, 1 x HDMI 1.4b, 1 x 2x2 Wireless antenna, 1 x Clear CMOS button, 1 x LAN (RJ45), 1 x Optical S/PDIF Out, 1 x 5.1-Channel audio jack, 2 x PCIe 3.0 x16, 3 x PCIe 3.0 x1, ATX, Matte White;
N7 Z490
The N7 Z490 is built around Intel's Z490 chipset to give you everything you need to build an incredible gaming PC.
It offers a variety of features such as built-in Wi-Fi 6, an integrated fan controller, and support for RGB accessories from all manufacturers.
You can create a visually seamless backdrop for your components by matching your motherboard cover to your NZXT case.
The NZXT N7 Z490 ATX LGA1200 Motherboard features everything builders need to complete their projects beautifully.
A streamlined board layout and integrated I/O simplify the building process on the N7 Z490. Using NZXT CAM, users can create fan curves or control RGB lighting from any manufacturer with built-in digital RGB and fan controls.
SMART CONTROLS
It includes key features from our RGB and Fan Controller, allowing users to control four channels of RGB lighting and seven channels of fan control intuitively through the CAM. Lights, accessories, and transformers from all manufacturers are supported.
STUNNING CRAFTSMANSHIP
Black or white covers for the N7 provide a clean design that blends seamlessly with your case.
BUILDING MADE EASIER
Despite having WiFi 6 connectivity, the N7 Z490 also utilizes all PCI express lanes available from the CPU and chipset, ensuring everything works properly.
N7's design streamlines installation with a rear I/O shield and optimally positioned headers for streamlined installation.
Specifications
Memory
| Memory slots type | DIMM |
| Number of memory slots | 4 |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Dual-channel |
| Non-ECC | |
| Supported memory clock speeds | 2133,2400,2666,2800,2933,3000,3200,3300,3333,3400,3466,3600,3733,3866,4000,4133,4266 MHz |
| Supported memory module capacities | 1GB,2GB,4GB,8GB,16GB,32GB |
| Maximum internal memory | 128 GB |
| Unbuffered memory |
Processor
| Processor manufacturer | Intel |
| Compatible processor series | Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9 |
| Processor socket | LGA1200 |
| Maximum number of SMP processors | 1 |
| Maximum internal memory supported by processor | 128 GB |
Storage controllers
| Supported storage drive types | HDD & SSD |
| Number of hard drives supported | 4 |
| RAID levels | 0,1,5,10 |
Internal I/O
| USB 2.0 connectors | 3 |
| USB 3.0 (3.1 Gen 1) connectors | 1 |
| USB 3.1 (3.1 Gen 2) connectors | 1 |
| Supported storage drive interfaces | M.2, Serial ATA III |
| Number of SATA III connectors | 4 |
| S/PDIF out connector | |
| Front panel audio connector | |
| ATX Power connector (24-pin) | |
| Number of EATX power connectors | 1 |
| CPU fan connector | |
| EPS power connector (8-pin) | |
| 12V power connector | |
| RGB LED pin header |
Back panel I/O ports
| HDMI ports quantity | 1 |
| HDMI version | 1.4b |
| Headphone outputs | 1 |
| S/PDIF out port | |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 2 |
| USB 3.1 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.1 (3.1 Gen 2) Type-C ports quantity | 1 |
| WiFi-AP antenna jack | 1 |
Networking
| Ethernet LAN | |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| LAN controller | Dragon RTL8125BG |
| Wi-Fi | |
| Wi-Fi standards | 802.11a,802.11b,802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Bluetooth | |
| Bluetooth version | 5.1 |
Features
| Audio chip | Realtek ALC1220 |
| Supported processor sockets | LGA 1200 (Socket H5) |
| Component for | PC |
| Motherboard chipset family | Intel |
| Cooling type | Active |
| Motherboard chipset | Intel Z490 |
| Motherboard form factor | ATX |
| Audio output channels | 8 channels |
| Windows operating systems supported | Windows 10 x64 |
| Certification | FCC, CE, WHQL, ErP/EuP Ready |
Graphics
| Maximum graphics adapter memory | 1024 MB |
| Graphics adapter family | Intel |
| Maximum resolution | 4096 x 2160 pixels |
| Discrete graphics support | |
| Graphics adapter | HD Graphics |
| On-board graphics adapter | |
| Parallel processing technology support | 2-Way CrossFireX |
Expansion slots
| PCI Express x1 (Gen 3.x) slots | 3 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| Number of M.2 (M) slots | 2 |
BIOS
| BIOS type | UEFI AMI |
| Clear CMOS button |
Power
| Power source type | ATX |
Other features
| Wi-Fi 6 (802.11ax) | |
| Intel Wi-Fi 6 AX200 | |
| 2 |
