StarTech.com MSA Compliant Transceiver Module - 100BASE-ZX
MPN
SFP100BZXST
UPC
065030873482
About this item
StarTech.com 100BASE-ZX SFP Transceiver Module - 100 Mbps - 80 km - MSA Compliant Fiber SFP
100 Mbps | Single Mode Fiber | LC | 80 km (49.7 mi) | Lifetime Warranty
The SFP100BZXST is an MSA compliant fiber SFP transceiver that’s designed, programmed and tested to work with 100BASE-ZX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 80 km (49.7 mi) and delivers dependable 100 Mb Ethernet connectivity over fiber cabling.
Technical Specifications:
Wavelength: 1550nm
Maximum Data Transfer Rate: 155 Mbps
Type: Single Mode Fiber
Connection Type: LC Connector
Maximum Transfer Distance: 80 km (49.7 mi)
Power Consumption: Less than 1 Watt
DDM: Yes
This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech SFPs
All StarTech SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech Advantage
- Delivers reliable 100Mbps connections for 100BASE-ZX compliant networks
- StarTech SFP modules are backed by a lifetime warranty
- Complies with Multi-Source Agreement (MSA) industry standards
The SFP100BZXST is an MSA compliant fiber SFP transceiver that’s designed, programmed and tested to work with 100BASE-ZX compatible MSA switches and routers. The SFP transceiver module supports a maximum distance of up to 80 km (49.7 mi) and delivers dependable 100 Mb Ethernet connectivity over fiber cabling.
Technical Specifications:
Wavelength: 1550nm
Maximum Data Transfer Rate: 155 Mbps
Type: Single Mode Fiber
Connection Type: LC Connector
Maximum Transfer Distance: 80 km (49.7 mi)
Power Consumption: Less than 1 Watt
DDM: Yes
This SFP fiber module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech SFPs
All StarTech SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech offers a wide variety of SFP modules and direct-attach SFP Cables, providing the convenience and reliability you need to ensure dependable network performance.
The StarTech Advantage
- Delivers reliable 100Mbps connections for 100BASE-ZX compliant networks
- StarTech SFP modules are backed by a lifetime warranty
- Complies with Multi-Source Agreement (MSA) industry standards
Specifications
Networking
| Data transfer rate (max) | 155 Mbit/s |
| Interface type | SFP |
| Fiber optic connector | LC |
| Networking standards | IEEE 802.3u |
| SFP transceiver type | ZX |
Performance
| Cable type | Fiber optic |
| Single-mode fiber (SMF) supported | |
| Wavelength | 1550 nm |
| Product colour | Silver |
| Housing material | Aluminium |
| Hot-Plug support | |
| Maximum transfer distance | 80000 m |
| Full duplex | |
| Duplex system | Full, Half |
| Wavelength-division multiplexing (WDM) |
Power
| Power consumption (typical) | 1 W |
Operational conditions
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
Weight & dimensions
| Width | 14 mm (0.55 ") |
| Depth | 60 mm (2.34 ") |
| Height | 16 mm (0.62 ") |
| Weight | 18 g (0.04 lbs) |
| Package width | 95 mm |
| Package depth | 118 mm |
| Package height | 34 mm |
| Package weight | 47 g |
Certificates
| Certification | CE, FCC, UR |
| RoHS compliance |
Packaging content
| Number of products included | 1 pc(s) |
