StarTech.com USB HDMI over Cat 5e / Cat 6 KVM Console Extender w/ 1080p Uncompressed Video - 330ft (100m)

Out of stock
SKU
14_SV565UTPHDU_1
$1,039.00
MPN
SV565UTPHDU
UPC
065030853057

About this item
StarTech.com USB HDMI over Cat 5e / Cat 6 KVM Console Extender w/ 1080p Uncompressed Video - 330ft (100m) KVM Extender Cat5e Cat6 HD Video
The SV565UTPHDU USB HDMI® KVM Extender lets you control a PC from up to 330ft (100m) away over a single Cat 5e or Cat 6 cable connection, with uncompressed 1080p HDMI video and access to up to 3 connected USB devices.
A flexible solution for powering large high-definition displays remotely, this HDMI USB extender supports uncompressed 1080p or 1920x1200 video resolutions at maximum distance. Additional features such as 3D support, HDCP, CEC and Lip Sync pass-through enable you to display your content exactly as you need it on the remote display.
This versatile KVM console extender can be connected to a single system, or cascaded to an existing KVM switch for remote operation of multiple systems, and features 3 USB 2.0 ports on the remote end, allowing you to connect a keyboard, mouse, printer or other peripherals. Since the extender uses Cat 5e (or better) network cable, you have the option to use existing infrastructure wiring, which helps avoid the hassle and expense of running bulky video cables.
Backed by a StarTech 2-year warranty and free lifetime technical support.

The StarTech Advantage

- Power a large HDMI display from a distance with uncompressed 1080p video
- Operate a single system or KVM switch remotely through KVM console extension
- Save time and money by extending over an existing Cat 5e / Cat 6 infrastructure cabling
Specifications
Features
Type AV transmitter & receiver
Connectivity technology Wired
Maximum transfer distance 100 m
Rack mounting
Maximum digital resolution 1920 x 1200 pixels
Product colour Black
Material Aluminium
Plug and Play
Certification CE, FCC, RoHS, UL
Transmitter
Transmitter video port type HDMI
Transmitter local keyboard/mouse port type USB
Receiver
Receiver local video port type HDMI
Power
AC input voltage 100-240 V
AC input frequency 50/60 Hz
AC adapter output voltage 5 V
AC adapter output current 3 A
Power consumption (transmitter) (max) 15 W
Power consumption (receiver) (max) 15 W
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 20 - 80 %
Packaging content
AC adapter included
Cables included AC, HDMI, USB
Quick installation guide
Packaging data
Package width 210 mm
Package depth 297 mm
Package height 110 mm
Package weight 2500 g
Technical details
Dimensions (WxDxH) 112 x 175 x 30 mm
Weight 847 g (1.87 lbs)
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for SV565UTPHDU by StarTech.com you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
