Hanwha XNP-9250R security camera IP security camera Outdoor Dome 3840 x 2160 pixels Ceiling/wall
MPN
XNP-9250R
About this item
1/2.8" CMOS, 3840x2160, 5-125mm, PTZ, RJ-45, MicroSD, IP66, PoE, 158x293.3 mm
1/2.8" CMOS, 3840x2160, 5-125mm, PTZ, RJ-45, MicroSD, IP66, PoE, 158x293.3 mm
Specifications
Performance
| Type | IP security camera |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | |
| Day/night mode | |
| Infrared (IR) cut-off filter |
Design
| Form factor | Dome |
| Product colour | Black, White |
| Mounting type | Ceiling/Wall |
| IK code | IK10 |
| International Protection (IP) code | IP66 |
| Housing material | Aluminium, Polycarbonate (PC) |
Video
| Maximum resolution | 3840 x 2160 pixels |
| Video compression formats | H.264, H.265, M-JPEG |
| Privacy masking | |
| Frame rate | 30 fps |
| Back Light Compensation (BLC) | |
| Video streaming | |
| Highlight Compensation (HLC) | |
| Flip & mirror | |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
Camera
| Camera pan control | |
| Camera tilt control | |
| Viewing angle, horizontal | 57.42 ° |
| Viewing angle, vertical | 33.54 ° |
| Tilt angle range | -20 - 90 ° |
| Tilt speed | 500 °/sec |
| Pan range | 0 - 360 ° |
| Pan speed | 250 °/sec |
| Pan preset speed | 700 °/sec |
| Camera shutter type | Electronic |
| Camera shutter speed | 2 - 1/12000 s |
Image sensor
| Number of sensors | 1 |
| Sensor type | CMOS |
| Optical sensor size | 1/2.8 " |
Lens system
| Zoom capability | |
| Digital zoom | 32 x |
| Number of lenses | 1 |
| Maximum aperture number | 1.6 |
| Minimum aperture number | 3.73 |
| Closest focusing distance | 3 m |
| Focal length range (f-f) | 5-125 mm |
Security
| IP address filtering | |
| HTTPS encryption | |
| Video motion detection |
Storage
| Card reader integrated | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Built-in hard drive | |
| Flash memory | 512 MB |
| Internal memory | 4000 MB |
| Maximum memory card size | 1000 GB |
Night vision
| Night vision | |
| Night vision distance | 200 m |
| LED type | IR |
Networking
| Ethernet LAN | |
| Ethernet interface type | Fast Ethernet |
| Wi-Fi | |
| Bluetooth | |
| Networking standards | IEEE 802.1x, IEEE 802.3at |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP |
| Quality of Service (QoS) support | |
| Number of users | 128 user(s) |
| Streaming method | Multicast, Unicast |
Ports & interfaces
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
Weight & dimensions
| Height | 293.3 mm (11.44 ") |
| Diameter | 158 mm |
| Weight | 3200 g (7.05 lbs) |
Power
| Power source type | DC, PoE |
| Power consumption (typical) | 20 W |
| Power consumption (max) | 25 W |
Operational conditions
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -50 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage relative humidity (H-H) | 0 - 95 % |
Packaging content
| Number of cameras | 1 |
