MSI MPG Z790 Edge Wi-Fi DDR4 Gaming Motherboard

MPN
MPG Z790 EDGE WIFI DDR4
UPC
824142301340

About this item

MSI MPG Z790 EDGE WIFI DDR4 LGA 1700 Intel Z790 SATA 6Gb/s DDR4 ATX Motherboard

The MSI MPG Z790 EDGE WIFI DDR4 is a gaming-oriented ATX motherboard that supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold, and Celeron® Processors with an LGA 1700 socket

It has a premium VRM design built with a total of 16 Phases Mirrored Power Arrangement with 90A SPS, which helps unleash and sustain maximum performance. The motherboard has a silver-white color scheme that is stylish and powerful.

Here are some of the key features of the MSI MPG Z790 EDGE WIFI DDR4:

  • Chipset: Intel Z790
  • Memory: 4x DDR4, Maximum Memory Capacity 128GB, Memory Support 5333/5200/5066/5000/4800/4600/4533/4400/4266/4000/3866/3733/3600/3466/3333(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz
  • M.2 Slots: 5x M.2, M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, supports 22110/2280/2260 devices, M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices, M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices, M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260/2242 devices, M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices
  • SATA: 7x SATA 6G
  • LAN: 2.5G LAN
  • Wireless: Intel® Wi-Fi 6E, Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (160MHz) up to 2.4Gbps, Supports 802.11 a/ b/ g/ n/ ac/ ax, Supports Bluetooth® 5.3, FIPS, FISMA
  • Audio: Realtek® ALC4080 Codec, 7.1-Channel USB High-Performance Audio, Supports up to 32-Bit/384 kHz playback on the front panel
  • Internal I/O: 1x Power Connector(ATX_PWR), 2x Power Connector(CPU_PWR), 1x CPU Fan, 1x Pump Fan, 6x System Fan, 2x Front Panel (JFP), 1x Chassis Intrusion (JCI), 1x Front Audio (JAUD), 1x TBT connector (JTBT, supports RTD3), 1x Tuning Controller connector(JDASH), 3x Addressable V2 RGB LED connector (JARGB_V2), 1x RGB LED connector(JRGB)

The motherboard has several ports, including Display Port, USB 3.2 Gen 1 5 Gbps (Type-A), USB 3.2 Gen 2 10Gbps (Type-A), HDMI™, Clear CMOS / Flash BIOS, USB.

Specifications
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for MPG Z790 EDGE WIFI DDR4 by MSI you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
