Samsung PM49F Signage Display 49"
MPN
PM49F
UPC
806088373348
About this item
124.46 cm (49") , 1920 x 1080, 8ms, EdgeLED, 20 W, 4000:1, 500 nit, HDMI x 2, USB 2.0 x 2, 100 - 240 V, 50/60 Hz, 13.2 kg, Black
Tizen-powered displays that can handle any business need in a slim, captivating design
Find displays that go beyond the limits of slim design
A compact, yet strong signage solution for environments restricted by space or configuration, Samsung's new PHF and PMF Series standalone displays offer the slimmest depth design in the industry (29.9mm).
PHF and PMF signage models are available in 43-, 49-, and 55-inch sizes, respectively. Additionally, PMF displays are available in a 32-inch format to help keep viewers' eyes focused on the on-screen content.
Unlock easier and more flexible control due to a centralized infrared receiver
Thanks to a centralized infrared receiver, control is easier and more flexible
By integrating a centralized infrared receiver (IR), the standalone displays enable easier and more flexible user control.
The IR signal can be received by all models via Central IR. By designing the installation or mounting to the user's specifications, the IR functionality can be accessed from anywhere, further enhancing uninterrupted performance.
Eliminate glare and guarantee high visibility and readability
Displays from the PHF and PMF Series have a non-glare frontal panel that keeps natural and ambient light interference to a minimum, ensuring continuous visibility.
Using this material in conjunction with QSR menu boards, or airport flight schedule boards with adequate natural light, the visibility and readability of the images is very high.
Enjoy peace of mind knowing that your display is protected from various environmental conditions
In addition to being dust-resistant and capable of sustaining a range of environmental conditions, Samsung's new PMF and PHF standalone displays are IP5X-certified.
Having this certification eliminates the risk of dust accumulating on displays installed on subway trains or on platforms outside.
In dusty environments, these IP5x certified displays can be conveniently used without the need for additional enclosures. Regardless of natural or interactive conditions, uninterrupted, 24/7 content delivery is always guaranteed.
Specifications
Display
| Display diagonal | 49 " |
| Display type | LED |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 500 cd/m² |
| HD type | Full HD |
| Response time | 8 ms |
| Contrast ratio (typical) | 4000:1 |
| Dynamic contrast ratio marketing name | Mega Contrast |
| Viewing angle, horizontal | 178 \u00b0 |
| Viewing angle, vertical | 178 \u00b0 |
| Display number of colours | 1.073 billion colours |
| Pixel pitch | 0.56 x 0.56 mm |
| Active display area (W x H) | 1073.779 x 604 mm |
| Display diagonal (metric) | 123 cm |
| Touchscreen | |
| Colour gamut | 72 % |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Supported video modes | 1080i,1080p |
| LED backlighting type | Edge-LED |
| Horizontal scan range | 30 - 81 kHz |
| Vertical scan range | 48 - 75 Hz |
Audio
| Built-in speaker(s) | |
| Number of speakers | 2 |
| RMS rated power | 20 W |
Design
| Design | Digital signage flat panel |
| Product colour | Black |
| VESA mounting | |
| VESA mounting interfaces | 400 x 400 mm |
| Bezel width (bottom) | 6.9 mm |
| Bezel width (side) | 8.9 mm |
| Bezel width (top) | 6.9 mm |
| Orientation | Horizontal |
| RoHS compliance |
Performance
| TV tuner integrated | |
| Multi-display supported | |
| Operating hours (hours/days) | 24/7 |
| HDCP | |
| On Screen Display (OSD) | |
| Plug and Play |
Ports & interfaces
| Ethernet LAN | |
| HDMI ports quantity | 2 |
| DVI port | |
| DVI-I ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232C | |
| USB version | 2.0 |
| DisplayPorts quantity | 2 |
| USB ports quantity | 2 |
Power
| Power consumption (typical) | 98 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (sleep) | 0.5 W |
| Power consumption (off) | 0.5 W |
| Energy efficiency class | B |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80 % |
Computer system
| Computer system | |
| Processor family | ARM Cortex |
| Processor model | Cortex-A12 |
| Processor frequency | 1.3 GHz |
| Processor cores | 4 |
| L2 cache | 32 KB |
| Internal memory | 2.5 GB |
| Memory clock speed | 1866 MHz |
| Internal storage capacity | 8 GB |
| Video formats supported | AVC, AVS, H.263, H.264, MPEG, MPEG1, MPEG2, MPEG4, VC-1, VP8, VP9 |
| Audio formats supported | AC3, DTS |
| Image formats supported | PNG |
| Graphics adapter Open GL support |
Weight & dimensions
| Width | 1092.6 mm (42.61 ") |
| Depth | 29.9 mm (1.17 ") |
| Height | 624.8 mm (24.37 ") |
| Weight | 13200 g (29.1 lbs) |
Packaging data
| Handheld remote control | |
| Batteries included | |
| Cables included | AC |
| Quick start guide | |
| Warranty card | |
| Package width | 1195 mm |
| Package depth | 167 mm |
| Package height | 721 mm |
| Package weight | 18100 g |
Technical details
| Audio out (Mini jack) | 1 |
| Audio in (mini jack) | 1 |
