LG 22SM3G-B signage display 54.6 cm (21.5") IPS Full HD Digital signage flat panel Built-in processor

In stock
SKU
12_22SM3G-B_1
$507.00
Eligible for Free Shipping & Free Returns
MPN
22SM3G-B
UPC
719192636200
About this item
22SM3G-B, 21.5", IPS, 1920 x 1080 (FHD), 250 cd/m², USB Plug & Play, Built-in Wi-Fi

22" Signage with More Utility for Commercial Space

22SM3G delivers information and performs guide with more effective ways in various commercial space, which provides more convenient solution thanks to its upgraded webOS platform.

High Performance SoC with webOS

Built-in Quad Core SoC can execute several tasks at once while providing smooth content playback without the need for a media player. Also, LG webOS smart signage platform enhances user convenience with intuitive GUI and simple app development tools.

Various Sensor Applications

LG webOS smart signage platform easily supports connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc, via USB plug-in. The overall cost for maintenance is reduced as there's no need to purchase additional software or media players.

A Wide Range of Interfaces

Through its diverse interfaces, users can connect the display with various sources for optimal use. Also, the failover function supports users preparing backup sources in case an unexpected error occurs.

USB Plug & Play

22SM3G supports USB Plug & Play feature, so users can easily set content playback using a USB.

Remote Monitoring and Control

Through the Control Manager, the embedded web monitoring solution, you can control and monitor the status of multiple 22SM3G displays in different locations in real-time. It is available on internet-connected devices, allowing you to flexibly and rapidly respond to emergency situations anywhere.

Real-time Care Service with LG Signage365Care

The maintenance gets easier and faster with the optional service Signage365Care*, a cloud service solution provided by LG service. It remotely manages status of displays in client workplaces for fault diagnosis and remote-control services, ensuring stable operation of the client’s business.
Specifications
Display
Display diagonal 21.5 "
Display type IPS
Display resolution 1920 x 1080 pixels
Display brightness 250 cd/m²
HD type Full HD
Contrast ratio (typical) 1000:1
Contrast ratio (dynamic) 400000:1
Viewing angle, horizontal 178 \u00b0
Viewing angle, vertical 178 \u00b0
Display diagonal (metric) 55.88 cm
Touchscreen
Native aspect ratio 16:9
Audio
Built-in speaker(s)
Number of built-in speakers 2
RMS rated power 2 W
Design
Design Digital signage flat panel
Product colour Black
VESA mounting
VESA mounting interfaces 100 x 100 mm
Orientation Horizontal
Certification CB, NRTL, EMC, FCC Class "A", CE, ErP
Performance
Wi-Fi
Purpose Universal
Operating hours (hours/days) 16/7
Ports & interfaces
Ethernet LAN
HDMI ports quantity 2
DVI port
Audio (L,R) in 1
Ethernet LAN (RJ-45) ports 1
RS-232 interface
USB port
RS-232C
USB ports quantity 1
USB version 2.0
Power
Power consumption (typical) 33 W
Power consumption (standby) 30 W
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Heat dissipation 7.89 BTU/h
Power consumption (sleep) 1 W
Power consumption (off) 0.5 W
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Operating relative humidity (H-H) 10 - 80 %
Storage temperature (T-T) -20 - 60 °C
Storage relative humidity (H-H) 5 - 85 %
Computer system
Computer system
Built-in processor
Processor cores 4
Internal memory 4 GB
Weight & dimensions
Width 510.3 mm (19.9 ")
Depth 53.8 mm (2.1 ")
Height 302.1 mm (11.78 ")
Weight 3340 g (7.36 lbs)
Packaging data
Handheld remote control
Batteries included
Cables included AC
Mounting kit
Package width 565 mm
Package depth 103 mm
Package height 357 mm
Package weight 3500 g
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for 22SM3G-B by LG you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
