Broadcom BCM5719-4P Internal Ethernet 1000 Mbit/s
About this item
- 4x RJ-45;
- PCIe 2.0 x4;
- 1GBASE-T;
- Wake-on-LAN;
Broadcom BCM5719-4P Internal Ethernet 1000 Mbit/s is best for multicore servers, delivering full line-rate throughput across all ports
It's designed for corporate and data center scenarios.
13th-generation
For high-performance server and networking applications, the BCM5719 PCIe NIC is a 13th-generation 10/100/1000BASE-T and 10/100/1000BASE-X Ethernet LAN controller solution.
Each LAN interface has its own PCI Express function supported by the host interface.
I/O Virtualization IOV features on the Broadcom BCM5719-4P Internal Ethernet 1000 Mbit/s include 17 receive and 16 transmit queues, as well as 17 MSI-X vectors with configurable vector-to-queue association.
The BCM5719 can handle VMWare NetQueue and Microsoft VMQ technologies thanks to these IOV characteristics. The BCM5719 has a large number of hardware characteristics that can be used by the system to accomplish IEEE 1588 or IEEE 802.1AS-based time synchronization. A high-precision clock, timestamp registers for receive/transmit packets, and programmable trigger inputs and watchdog outputs are among the hardware features.
Specifications
Ports & interfaces
| Connectivity technology | Wired |
| Internal | |
| Host interface | PCI Express |
| Interface | Ethernet |
| Ethernet LAN (RJ-45) ports | 4 |
| PCI version | 2.0 |
Bandwidth
| Data transfer rate (max) | 1000 Mbit/s |
| Full duplex |
Networking
| Ethernet LAN | |
| Cabling technology | 10/100/1000BaseT(X) |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3ap, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Jumbo frames | 1500 |
| Jumbo frames support |
Performance
| Wake-on-LAN ready |
System requirements
| Other operating systems supported | Novell Open Enterprise Server 11, VMware vSphere 5.0+ |
| Server operating systems supported | Windows Server 2008, Windows Server 2008 R2, Windows Server 2012 |
Operational conditions
| Operating temperature (T-T) | 0 - 55 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
Other features
| Server | |
| CE, RoHS |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
BCM95719A1904AC by Broadcom
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
