Cisco CBW140AC 867 Mbit/s White Power over Ethernet (PoE)

Out of stock
SKU
14_5-CBW140AC-B_1
$408.00
MPN
5-CBW140AC-B

About this item

CBW140AC 802.11ac 2x2 Wave 2 Access Point Ceiling Mount, B regulatory domain

The Cisco® Business 140AC Access Point is the perfect solution for small businesses looking to improve their wireless network

It delivers top-notch performance, with support for the latest Wi-Fi standard, IEEE’s 802.11ac Wave 2, and features mesh technology for increased flexibility. This access point can handle an increasing number of high-bandwidth devices and applications that will soon become commonplace in modern networks.

The Cisco Business 140AC Access Point extends coverage and capacity to Wi-Fi clients, such as smartphones, tablets, and laptops, that have integrated 802.11ac Wave 1 or Wave 2 support. With its dual radios and dual bands, it provides a total aggregate dual-radio data rate of up to 1 Gbps, which is more than what access points that support the 802.11n standard can deliver. This makes it the perfect choice for small businesses that expect high-performance wireless connectivity.

With integrated mesh technology, the Cisco Business 140AC Access Point provides deployment flexibility that is simple and secure. You can expand coverage and capacity using Cisco Business wireless mesh extenders, which can be placed on a desktop, plugged into an AC electrical outlet, or mounted directly to a wall.

Managing the Cisco Business 140AC Access Point is easy with the Cisco Business Mobile app

This intuitive client application simplifies the traditional challenges associated with wireless network deployment, right from your mobile device. You can easily extend your network by adding new mesh extenders using Quick Response (QR) codes and wireless network activation in minutes. The app also provides a real-time snapshot of network usage, traffic patterns, and network throughput, ensuring optimal user experience.

The Cisco Business 140AC Access Point is powered by 802.3af PoE standard, and it features a single Gigabit Ethernet uplink port

It also comes with flexible mounting options, making it easy to install directly on the ceiling (including T-bar rail mounting) or a wall.

In summary, the Cisco Business 140AC Access Point is an ideal solution for small businesses that want to improve their wireless network performance and coverage. It's easy to manage and install and comes with the latest technology to provide a secure and reliable wireless connection.

Specifications
Performance
Ethernet LAN data rates 10,100,1000 Mbit/s
Data transfer rate (max) 867 Mbit/s
2.4 GHz
5 GHz
Frequency band 2.412 - 2.462; 5.180 - 5.320; 5.500 - 5.720; 5.745 - 5.825 GHz
Number of users 400 user(s)
MIMO
MIMO type Multi User MIMO
Remote Authentication Dial-In User Service (RADIUS)
Networking standards IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3af
Flash memory 256 MB
Transmitting power 20 dBmW
Internal memory 1024 MB
Wi-Fi Multimedia (WMM)/(WME)
VLAN support
Channels quantity 36 channels
Processor frequency 710 MHz
Certification UL 60950-1 CAN/CSA-C22.2 No. 60950-1 UL 2043 IEC 60950-1 EN 60950-1 FCC 15.247, 15.407 RSS-247 (Canada) EN 300.328, EN 301.893 (Europe) ARIB-STD 66 (Japan) ARIB-STD T71 (Japan) EMI (Class B) FCC Part 15.107 / 15.109 ICES-003 (Canada) VCCI (Japan) EN 301.489-1 / -17 (Europe) EN 50385 FCC OET-65C RSS-102
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
Cabling technology 10/100/1000Base-T(X)
Security
Security algorithms 802.1x RADIUS, AES, EAP-FAST, EAP-GTC, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, WPA2, WPA3
MAC address filtering
Antenna
Antenna type Internal
Antenna features Integrated antenna
Antenna gain level (max) 4 dBi
Power
Power consumption (max) 8.3 W
Power over Ethernet (PoE)
Design
Placement Ceiling
Product colour White
Features
Maximum data transfer rate (2.4 GHz) 300 Mbit/s
Maximum data transfer rate (5 GHz) 867 Mbit/s
Software
Dynamic Frequency Selection (DFS)
Operational conditions
Operating relative humidity (H-H) 10 - 90 %
Operating temperature (T-T) 0 - 50 °C
Storage temperature (T-T) -30 - 70 °C
Storage relative humidity (H-H) 10 - 90 %
Non-operating altitude 3000 - 4500 m
Operating altitude 0 - 3000 m
Weight & dimensions
Width 150.8 mm (5.88 ")
Depth 150.8 mm (5.88 ")
Height 33 mm (1.29 ")
Weight 400 g (0.88 lbs)
Packaging content
Number of products included 5 pc(s)
Other features
Y
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for 5-CBW140AC-B by Cisco you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
