EnGenius Cloud6E 4x4x4
MPN
ECW336
UPC
655216010147
About this item
2.4 GHz + 5 GHz + 6 GHz, IEEE 802.11ax, 802.11a/b/g/n/ac, MU-MIMO, 205 x 205 x 33.2 mm, 630 g
EnGenius Cloud Managed Wi-Fi 6 4x4x4 Access Point ECW336 supports tri-concurrent 802.11ax Wi-Fi 6 architecture, delivering supercharged speeds up to 4,800 Mbps on 6 GHz, 2,400 Mbps (5 GHz), and up to 1,200 Mbps (2.4 GHz). With WPA3 & WPA2-AES authentication support, remote monitoring & troubleshooting, and Mesh Wireless Support for optimized signal quality, it's easy to set up and manage an unlimited number of APs with the EnGenius Cloud App.
Specifications
Performance
| Ethernet LAN data rates | 10,100,1000,2500,5000 Mbit/s |
| Data transfer rate (max) | 8348 Mbit/s |
| Spread spectrum method | DSSS |
| 2.4 GHz | |
| 5 GHz | |
| MIMO | |
| MIMO type | Multi User MIMO |
| Wi-Fi Multimedia (WMM)/(WME) | |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3at |
| Quality of Service (QoS) support | |
| VLAN support | |
| Processor model | Qualcomm Networking Pro 1210 |
| Reset button | |
| Certification | FCC, CE |
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack |
Security
| Security algorithms | SNMP, SNMPv2, SNMPv3, WPA2-AES, WPA2-Enterprise, WPA3-Enterprise, WPA3-PSK |
| Service Set Identifier (SSID) features | Hidden SSID, Multiple SSIDs |
| Number of SSID support | 8 |
| MAC address filtering |
Antenna
| Antenna type | Internal |
| Antenna features | Integrated antenna |
| Antenna gain level (max) | 6 dBi |
| Antennas quantity | 12 |
Power
| Power consumption (max) | 22.5 W |
| Power over Ethernet (PoE) |
Design
| Placement | Ceiling, Wall |
| Product colour | White |
| LED indicators | LAN, Power, WLAN |
Features
| 6 GHz | |
| Maximum data transfer rate (2.4 GHz) | 1148 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2400 Mbit/s |
| Maximum data transfer rate (6 GHz) | 4800 Mbit/s |
| Virtual LAN features | Tagged VLAN |
| BeamForming |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 80 °C |
Weight & dimensions
| Width | 210 mm (8.19 ") |
| Depth | 210 mm (8.19 ") |
| Height | 33.2 mm (1.29 ") |
| Weight | 607 g (1.34 lbs) |
| Package width | 245 mm |
| Package depth | 245 mm |
| Package height | 85 mm |
| Package weight | 1134 g |
Packaging content
| Mounting kit | |
| Quick start guide | |
| Number of products included | 1 pc(s) |
Other features
| Y |
Note:
Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for
ECW336 by ENGENIUS
you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
Similar Products
View More-
Hewlett Packard EnterpriseHewlett Packard Enterprise R6M49A wireless access point 1774 Mbit/s Power over Ethernet (PoE) White (R6M49A)
$240.00 -
-
-
-
-
-
-
-
-
-
Hewlett Packard EnterpriseHPE Instant On Outdoor AP27 (US) 1774 Mbit/s White Power over Ethernet (PoE) (S1T36A)
$315.00 -
-
Ubiquiti NetworksUbiquiti U7 Pro Wall 5700 Mbit/s White Power over Ethernet (PoE) (U7-PRO-WALL)
$214.00 -
Ubiquiti NetworksUbiquiti U7 Pro Max 5700 Mbit/s White Power over Ethernet (PoE) (U7-PRO-MAX)
