Intel Core i7-13700F processor 30 MB Smart Cache Box

Out of stock
SKU
9_BX8071513700F_1
$358.00
MPN
BX8071513700F
UPC
735858528276

About this item
Boxed Intel® Core™ i7-13700F Processor (30M Cache, up to 5.20 GHz) FC-LGA16A

Intel® Gaussian & Neural Accelerator

Intel® Gaussian & Neural Accelerator (GNA) is an ultra-low power accelerator block designed to run audio and speed-centric AI workloads. Intel® GNA is designed to run audio based neural networks at ultra-low power, while simultaneously relieving the CPU of this workload.

Intel® Deep Learning Boost (Intel® DL Boost)

A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Deep Learning Boost (Intel® DL Boost)

A new set of embedded processor technologies designed to accelerate AI deep learning use cases. It extends Intel AVX-512 with a new Vector Neural Network Instruction (VNNI) that significantly increases deep learning inference performance over previous generations.

Intel® Speed Shift Technology

Intel® Speed Shift Technology uses hardware-controlled P-states to deliver dramatically quicker responsiveness with single-threaded, transient (short duration) workloads, such as web browsing, by allowing the processor to more quickly select its best operating frequency and voltage for optimal performance and power efficiency.

Intel® Turbo Boost Max Technology 3.0

Intel® Turbo Boost Max Technology 3.0 identifies the best performing core(s) on a processor and provides increased performance on those cores through increasing frequency as needed by taking advantage of power and thermal headroom.

Idle States

Idle States (C-states) are used to save power when the processor is idle. C0 is the operational state, meaning that the CPU is doing useful work. C1 is the first idle state, C2 the second, and so on, where more power saving actions are taken for numerically higher C-states.

Intel® Volume Management Device (VMD)

Intel® Volume Management Device (VMD) provides a common, robust method of hot plug and LED management for NVMe-based solid state drives.

Intel® AES New Instructions

Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Specifications
Processor
Processor family Intel Core i7
Processor cores 16
Processor socket LGA 1700
Processor model i7-13700F
Processor threads 24
Processor operating modes 64-bit
Processor cache 30 MB
Processor cache type Smart Cache
Box
Processor boost frequency 5.2 GHz
Processor codename Raptor Lake
Memory
Maximum internal memory supported by processor 128 GB
Memory types supported by processor DDR4-SDRAM, DDR5-SDRAM
Memory channels Dual-channel
Memory bandwidth (max) 89.6 GB/s
Graphics
On-board graphics adapter
Discrete graphics adapter
On-board graphics adapter model Not available
Discrete graphics adapter model Not available
Features
Execute Disable Bit
Idle States
Thermal Monitoring Technologies
Maximum number of PCI Express lanes 20
PCI Express slots version 4.0,5.0
PCI Express configurations 1x16+1x4,2x8+1x4
Supported instruction sets AVX 2.0, SSE4.1, SSE4.2
Scalability 1S
CPU configuration (max) 1
Embedded options available
Market segment Desktop
Harmonized System (HS) code 8542310001
Export Control Classification Number (ECCN) 5A992C
Commodity Classification Automated Tracking System (CCATS) 740.17B1
Processor special features
Intel® AES New Instructions (Intel® AES-NI)
Intel® Speed Shift Technology
Enhanced Intel SpeedStep Technology
Intel® Hyper Threading Technology (Intel® HT Technology)
Intel® Turbo Boost Technology 2.0
Intel Turbo Boost Max Technology 3.0
Intel 64
Intel® Secure Key
Intel® Deep Learning Boost (Intel® DL Boost)
Intel Virtualization Technology (VT-x)
Intel® OS Guard
Intel® Volume Management Device (VMD)
Intel Virtualization Technology for Directed I/O (VT-d)
Intel VT-x with Extended Page Tables (EPT)
Intel® Boot Guard
Mode-based Execute Control (MBE) Y
Operational conditions
Tjunction 100 °C
Technical details
Launch date Q1'23
Weight & dimensions
Processor package size 45 x 37.5 mm
Other features
L2 cache 24576 KB
Y
8
5.1
8
PC/Client/Tablet
2.1
Intel Core i7-13xxx
8
Intel
4.1
Y
Y
1.5
Y
65
5.2
4.0
219
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for BX8071513700F by Intel you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
