NZXT H510 Compact ATX Mid-Tower Case Tempered Glass

NZXT - H510 is elegant, simplistic, and modern - it is black, made of steel, with tempered glass, and minimal in appearance - the perfect match for a minimalist office PC

Their new lineup still features the elements builders loved in the original H Series, including their patented cable management system, removable fan/radiator mounting brackets, and easy-to-use drive trays.

Iconic H Series PC cases

Alongside new updates like a front-panel USB-C connector supporting high-speed USB 3.1 Gen 2 devices and a tempered glass side panel that installs with a single thumbscrew.

With a USB 3.1 Gen2-compatible USB-C connector on the front panel, it’s easier than ever to connect smartphones, high-speed external storage, or the latest peripherals to your PC.

The clean, modern design, iconic cable management bar, and uninterrupted tempered-glass side panel showcases your stunning build.

Cable management can often take more time than assembly. NZXT have designed a cable routing kit with pre-installed channels and straps, for intuitive and easy wiring.

Two Aer F120mm fans are included for optimal internal airflow and the front panel and PSU intakes include removable filters. Includes a removeable bracket designed for radiators up to 280mm simplifies the installation of either closed-loop or custom-loop water cooling.

Clean, fit-for-purpose, and effective

If you are going to be adding an AIO or extra fans you are definitely going to want to consider the H510 though. From water-cooling to budget builds, everything will look amazing inside this NZXT case, it is truly a mid-tower for all. The NZXT is perfect for new and experienced builders and the H510  compact mid-tower ATX case is stunning and an excellent value.

Perfect when you want a small-footprint ATX case without sacrificing features. A removable radiator mounting bracket, flush tempered glass window, multiple fan filters, and front USB 3.1 Gen 2 type-C are just some of the amenities.

The H510  compact mid-tower ATX case is stunning and an excellent value. A removable radiator mounting bracket, flush tempered glass window, multiple fan filters, and front USB 3.1 Gen 2 type-C are just some of the amenities.

Dimensions

The chassis measures 210 x 435 x 428mm (W x H D) without the feet. With them, the only changes will be in the case’s height, which will be 460mm from 435mm. When it comes to its weight, the case is 6.6kg in total.

For motherboards, the case supports mini-ITX, ATX, and Micro ATX. There are three available drive bays for 2.5” and 3.5” drives. There are seven expansion slots available where the front supports two 140mm or two 120mm radiators with pull.

Modernize

With a USB 3.1 Gen2-compatible USB-C connector on the front panel, it’s easier than ever to connect smartphones, high-speed external storage, or the latest peripherals to your PC. The clean, modern design, iconic cable management bar, and uninterrupted tempered-glass side panel showcase your stunning build.

Enjoyable Bildings

Cable management can often take more time than assembly , but with cable routing kit with pre-installed channels and straps the wiring is intuitive and easy. NZXT cases offer Gaming PC Builder a high-quality enclosure that simplifies the building process.

• Front I/O USB Type-C Port and Tempered glass side panel with single screw installation
• ENHANCED CABLE MANAGEMENT: Our patented cable routing kit with pre-installed channels and straps makes wiring easy and intuitive
• STREAMLINED COOLING: Two Aer F120mm fans* included for optimal internal airflow and the front panel and PSU intakes include removable filters, removeable bracket designed for radiators up to 240mm - simplifies the installation of either closed-loop or custom-loop water cooling
• MOTHERBOARD SUPPORT: Mini-ITX, MicroATX, and ATX

Clean Design

Everything about the sleek H510 appearance is calculated and clean. The professional exterior looks superb when combined with the uninterrupted tempered glass panel. Furthermore, the cable bar and PSU shroud go a long way to making the interior look spotless, giving even the most inexperienced builders something to be proud of.

Airflow

The case is expertly designed and the two 120mm Aer fans that accompany the chassis work in unison to create fantastic airflow. Regardless, there are plenty of removable dust filters and a bracket to simplify the installation of a radiator.

USB-C

The Type-C connector is on the front panel, meaning you can easily connect your phone or new gaming headset without having to drag the case from under your desk.

Fan Support

For fan support, the case allows for two 120mm or two 140mm fans in front. The top has space for a 120mm or 140mm fan; specifically, it’s the Aer F-120 case version that’s included. Looking at its rear, the H510 Compact Mid Tower Case also features a slot for one 120mm fan. Pre-installed on this portion is the inclusive Aer F-120 case version as well.

Clearance

For the case’s clearance specifications, there are allotted space for 19 to 23mm cables for management. As for the GPU, there’s up to 381mm available clearance without the front water cooler installed. If it’s installed, there’s up to 325mm clearance available.

The chassis has enough space for a CPU cooler that measures up to 165mm. The front and rear radiator allow 60mm for each. This case can also accommodate a reservoir and pump that’s up to 180mm along the cable bar. When it’s along the bottom panel, it allows up to 86mm.
