Pelco SRXE4-4V9-EBT-IR1 security camera Bullet IP security camera Indoor & outdoor 2688 x 1520 pixels Wall
MPN
SRXE4-4V9-EBT-IR1
About this item
1/1.8" CMOS, 4MP, 2688x1520px, 70m IR, PoE/DC, 25W
Sarix Enhanced 4 Series Bullet
The Sarix Enhanced 4 Series bullet camera introduces new analytical capabilities and sets a higher standard for security by running multiple analytics at once. Designed with a built-in microphone, identify loud noises, while recording audio when necessary. Be fully aware of your surroundings and respond to an event before it unfolds.
Crowd Threshold Detection
Set a crowd size limit and get alerts if it exceeds within the camera's view
Privacy Blurring
Uphold privacy standards by blurring out vehicles and people within a recorded or live-stream
Vehicle Sub-classes
Classify and trigger rules based on vehicle types like cars, trucks, bikes and motorcycles
Facet Metadata
Identify basic features to enhance operational efficiency, accelerate incident response and aid in investigations
Person Crawling
Detect a human event based on when a person is crawling
Audio Analytics
Analyze and be notified when loud and unusual noises are detected
Specifications
Performance
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | |
| Day/night mode | |
| Dynamic range | 120 dB |
| Infrared (IR) cut-off filter |
Design
| Form factor | Bullet (shape) |
| Product colour | Black, Grey |
| Mounting type | Wall |
| Weatherproof | |
| International Protection (IP) code | IP54, IP66, IP67, IP68 |
| Housing material | Aluminium, Polycarbonate (PC) |
| IK code | IK10 |
Video
| Maximum resolution | 2688 x 1520 pixels |
| Total megapixels | 4 MP |
| Video compression formats | H.264, H.265, M-JPEG |
| Supported graphics resolutions | 384 x 288,512 x 288,512 x 384,640 x 360,640 x 480 (VGA),768 x 432,768 x 576,800 x 600 (SVGA),1280 x 960,1600 x 1200 (UXGA),1600 x 1200,1920 x 1080 (HD 1080),1920 x 1440,2560 x 1440,2688 x 1520 |
| Video streaming | |
| Back Light Compensation (BLC) | |
| Privacy masking | |
| Frame rate | 60 fps |
Camera
| Minimum illumination | 0.003 lx |
| Lens viewing angle, horizontal | 35 - 111 u00b0 |
| Lens viewing angle, vertical | 35 - 109 u00b0 |
| Tilt angle range | -90 - 90 u00b0 |
| Angle of rotation | 350 u00b0 |
| White balance | Auto, Manual |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/7.5 - 1/15000 s |
| Number of Privacy masking areas | 64 |
Image sensor
| Number of sensors | 1 |
| Sensor type | CMOS |
| Progressive scan | |
| Optical sensor size | 1/1.8 " |
Lens system
| Zoom capability | |
| Number of lenses | 1 |
| Maximum aperture number | 1.3 |
| Auto focus | |
| Focal length range (f-f) | 4.4 - 9.3 mm |
Security
| Password protection | |
| Video motion detection | |
| Active tampering alarm | |
| Intelligent Video Surveillance (IVS) system features | Human detection, Line crossing detection, Moving object, Region entrance detection, Region exiting detection, Vehicle detection |
| Digest authentication | |
| Security algorithms | 802.1x RADIUS, FIPS 140-2, SNMPv2, SNMPv3 |
| HTTPS encryption |
Storage
| Card reader integrated | |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| ROM capacity | 4000 MB |
| Flash memory | 4000 MB |
Night vision
| Night vision | |
| Night vision distance | 70 m |
| LED type | IR |
Networking
| Ethernet LAN | |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Networking standards | IEEE 802.3af |
| Supported network protocols | IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMP, ICMP, DHCP, Zeroconf, ARP, HSTS |
| Streaming method | Multicast |
Ports & interfaces
| Connectivity technology | Wired |
| USB port | |
| Ethernet LAN (RJ-45) ports | 1 |
Audio
| Audio formats supported | G.711, PCM |
| Built-in microphone |
Weight & dimensions
| Width | 133 mm (5.19 ") |
| Depth | 309 mm (12.05 ") |
| Height | 133 mm (5.19 ") |
| Weight | 2110 g (4.65 lbs) |
Power
| Power source type | DC, PoE |
| Power consumption | 25 mA |
Certificates
| Certification | UL, cUL, CE, ROHS, RCM, UKCA, NOM, KC, BIS, UL 62368-1, CSA 62368-1, IEC/EN 62368-1, IEC 62471 |
Operational conditions
| Operating temperature (T-T) | -50 - 65 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 100 % |
Packaging content
| Number of cameras | 1 |
