Tripp Lite 10/100 SC Multimode Media Converter, 550M, 850nm

Out of stock
SKU
14_N784-001-SC-MM_1
$85.00
MPN
N784-001-SC-MM
UPC
037332183934

About this item
10/100 SC Multimode Media Converter, 550M, 850nm
Tripp Lite's N784-001-SC-MM 10/100 to Multimode Media Converter ( RJ45 to SC ) is an economical way to extend the distance of network nodes up to 550 Meters by converting Cat5e UTP cables to Multimode Fiber Optic. The Media Converter features automatic MDI/MDI-X configuration, and the UTP port senses the network speed automatically. Auto-detects half or full duplex operation on the fiber port. Power supplied by small form factor AC adapter.

- Extends a 100Mb Ethernet signal up to 550M over Multimode Fiber Optic Cable
- 10/100 UTP to SC Multimode Fiber converter
- Up to 550M (1800-ft.) range
- Auto-detects Full / Half Duplex Transfer Mode
- Auto Negotiation MDI / MDI-X
- 6 performance monitoring LEDs
- 850nm wavelength
- Small, compact design
Specifications
Networking
Data transfer rate (max) 100 Mbit/s
Converter input interface 100Base-TX
Ethernet interface type Fast Ethernet
Ethernet LAN data rates 10,100 Mbit/s
Auto MDI/MDI-X
Duplex system Full, Half
Ports & interfaces
Connectivity technology Wired
Ethernet LAN (RJ-45) ports 1
Fiber optic connector SC
DC-in jack
Performance
Maximum transfer distance 550 m
Wavelength 850 nm
Fiber mode structure Multi-mode
Design
Internal
LED indicators Y
Product colour Black
RoHS compliance
Power
Input voltage 100 - 240 V
AC input frequency 50 - 60 Hz
Output voltage 5 V
Output current 1.2 A
Note: Please be aware that availability, promotions, and descriptions may change without notice, but you can feel confident knowing that the price for N784-001-SC-MM by Tripp Lite you see now, is the price you pay. If you have any questions, our customer care team is available to assist you.
